LX1FL110

Schneider Electric

Schneider Electric LX1FL110 TeSys F Contactor Coil

SKU LX1FL110

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: LX1FL110
  • Origin France
  • Product Type: Accessories
  • Payment: T/T, Western Union
  • Weight: 1.47 kg
  • Dimensions: 22,5cm x 12cm x 10cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Accessories TeSys
Quantity
Call sales Contact

Product Description

Description

The LX1FL110 is a replacement control coil designed specifically for the TeSys F contactor LC1-F630. This coil is engineered for reliable operation at a supply voltage of 110/120 V AC across a frequency range of 40-400 Hz. As a critical component for contactor maintenance and repair, this coil ensures the precise electromechanical actuation required for high-power switching applications in industrial environments.

Features

  • Compatibility: Designed for TeSys F contactor model LC1-F630
  • Voltage: 110/120 V AC
  • Frequency: 40-400 Hz
  • Function: Actuation coil for contactor switching
  • Construction: Robust design suitable for industrial electrical cabinet environments

Applications

  • Maintenance and repair of TeSys F contactor systems
  • Replacement of worn or damaged contactor coils
  • Industrial motor control and power distribution panels
  • Automation systems requiring high-power switching contactors

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Brand Schneider Electric
Product Range TeSys D (TeSys F series compatible)
Product Type Contactor Coil
Control Voltage 110/120 V AC
Frequency 40-400 Hz
Dimensions 22.50 cm x 12.00 cm x 10.00 cm
Weight 1.47 kg
Product Phase Phase-Out

Installation Guidelines

  • Preparation: Ensure the power supply is completely isolated and locked out before attempting to replace the coil in the LC1-F630 contactor.
  • Access: Open the contactor housing to access the coil assembly, following the specific disassembly instructions provided in the contactor’s service manual.
  • Replacement: Carefully remove the old coil and slide the new LX1FL110 coil into place, ensuring the magnetic core and springs are correctly aligned.
  • Connection: Secure the control wiring to the coil terminals, ensuring tight, vibration-resistant connections.
  • Testing: After reassembly, verify the contactor’s operation by applying the rated control voltage to ensure smooth engagement and disengagement of the main contacts.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What contactor model is the LX1FL110 coil compatible with?
This coil is designed for the Schneider Electric TeSys F contactor LC1-F630.
What is the voltage and frequency rating of this coil?
It operates at 110/120 V AC with a frequency range of 40-400 Hz.
Is this coil still in active production?
No, this product is currently in the Phase-Out lifecycle stage.
Reviews

More from this brand

Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
170XTS00200Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
Schneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
TSXP57303AMCSchneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
170ADM69051Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
Schneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive
ATV212WU22N4CSchneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive

LX1FL110

Stock & lead time on request

Call
  • LX1FL110
1 1

Schneider Electric LX1FL110 TeSys F Contactor Coil

Only 7 item(s) left in stock

  • Manufacturer: Schneider Electric

  • Product No.: LX1FL110

  • Country of origin:France

  • Product Type: Accessories

  • Payment: T/T, Western Union

  • Weight: 1470g

  • Dimensions: 22,5cm x 12cm x 10cm

  • Shipping port: Xiamen

  • Warranty: 12 months

View full details
Product Description
FAQ
Shipping Returns
Additional details
Reviews

Description

The LX1FL110 is a replacement control coil designed specifically for the TeSys F contactor LC1-F630. This coil is engineered for reliable operation at a supply voltage of 110/120 V AC across a frequency range of 40-400 Hz. As a critical component for contactor maintenance and repair, this coil ensures the precise electromechanical actuation required for high-power switching applications in industrial environments.

Features

  • Compatibility: Designed for TeSys F contactor model LC1-F630
  • Voltage: 110/120 V AC
  • Frequency: 40-400 Hz
  • Function: Actuation coil for contactor switching
  • Construction: Robust design suitable for industrial electrical cabinet environments

Applications

  • Maintenance and repair of TeSys F contactor systems
  • Replacement of worn or damaged contactor coils
  • Industrial motor control and power distribution panels
  • Automation systems requiring high-power switching contactors

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Brand Schneider Electric
Product Range TeSys D (TeSys F series compatible)
Product Type Contactor Coil
Control Voltage 110/120 V AC
Frequency 40-400 Hz
Dimensions 22.50 cm x 12.00 cm x 10.00 cm
Weight 1.47 kg
Product Phase Phase-Out

Installation Guidelines

  • Preparation: Ensure the power supply is completely isolated and locked out before attempting to replace the coil in the LC1-F630 contactor.
  • Access: Open the contactor housing to access the coil assembly, following the specific disassembly instructions provided in the contactor’s service manual.
  • Replacement: Carefully remove the old coil and slide the new LX1FL110 coil into place, ensuring the magnetic core and springs are correctly aligned.
  • Connection: Secure the control wiring to the coil terminals, ensuring tight, vibration-resistant connections.
  • Testing: After reassembly, verify the contactor’s operation by applying the rated control voltage to ensure smooth engagement and disengagement of the main contacts.
Key Features:
#Accessories #TeSys

What contactor model is the LX1FL110 coil compatible with?
This coil is designed for the Schneider Electric TeSys F contactor LC1-F630.

What is the voltage and frequency rating of this coil?
It operates at 110/120 V AC with a frequency range of 40-400 Hz.

Is this coil still in active production?
No, this product is currently in the Phase-Out lifecycle stage.

Global Express Shipping

  • Standard Delivery: 4-6 Business Days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries, including rapid delivery to Saudi Arabia and UAE.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our professional technical warranty.

Orders are processed and delivered Monday-Friday (excluding public holidays).


For full eligibility, restocking fees, and international return details, please view our official Refund & Return Policy .

TECHNICAL SPECIFICATIONS

Color pattern
Black
Country of origin
France
Power source
AC-powered
