Schneider Electric TM2ARI8LT Modicon M241 Temperature Input Module

Description

Process temperature monitoring within the Modicon M241 system is managed via the Schneider Electric TM2ARI8LT analog input module. This hardware expansion unit provides eight dedicated channels for high-density temperature measurement using resistance temperature detectors (RTDs).

The module interfaces directly with standard PT100 and PT1000 sensors. It processes the analog thermal signals and transmits digitized temperature data directly to the host PLC CPU backplane. Equipped with removable connection terminal blocks, this expansion unit simplifies integration, maintenance, and wiring swaps on the factory floor.

Features

• Eight independent analog input channels dedicated to RTD thermal sensors.
• Direct compatibility with standard PT100 and PT1000 sensor types.
• Seamless bus integration with Modicon M241 and M251 logic controllers.
• Removable screw terminal blocks for simplified wiring and field maintenance.
• Compact industrial form factor optimized for standard 35 mm DIN rail mounting.

Applications

• Industrial furnace and oven thermal regulation.
• HVAC and environmental control systems.
• Chemical and food process engineering.
• Boiler and heat exchanger monitoring.

Technical Specifications

Installation Guidelines

• Ensure all electrical power is disconnected from the PLC backplane before mounting or removing the module.
• Mount the module vertically onto a standard 35 mm DIN rail within a protective industrial enclosure.
• Utilize shielded, twisted-pair cabling for all RTD sensor runs to prevent external electromagnetic noise from degrading signals.
• Keep low-voltage sensor cabling separated from high-voltage motor and power distribution wiring.
• Properly ground the cable shields at the entry point of the electrical cabinet.
