Schneider Lexium 28 LXM28AU02M3X Motion Servo Drive

Description

The LXM28AU02M3X is a Motion Servo Drive from the Lexium 28 series, engineered by Schneider Electric to provide high-precision motion control for industrial applications. This drive is designed to operate with either single-phase (1P) or three-phase (3P) power supplies at 200/230V, delivering a power output of 200W. The LXM28AU02M3X is a key component in automated motion systems, offering responsive torque and speed regulation for diverse mechanical loads. It remains an active product in the Schneider Electric catalog, ensuring ongoing support and compatibility for modern automation architectures.

Features

• Supports 1P/3P power supply (200/230V)
• Nominal power output: 200W
• Compact design for optimized cabinet space utilization
• High-performance motion control for precision mechanical applications
• Active product lifecycle status for reliable supply chain availability

Applications

• Material handling and conveyor systems
• Packaging and bottling machinery
• Labeling and printing equipment
• Precision robotics and assembly lines
• Automated alignment systems

Technical Specifications

Installation Guidelines

• Ensure the drive is mounted vertically in a clean, ventilated enclosure to maintain optimal thermal operating conditions.
• Provide at least 50mm of clearance above and below the drive for proper airflow.
• Always connect the motor cable shield to the designated ground terminal on the drive to minimize electromagnetic interference (EMI).
• Use shielded twisted-pair cables for encoder feedback signals to ensure data integrity during high-speed operation.
• Verify that the input voltage matches the drive specifications (200/230V) prior to energizing the system.
• Ensure all terminal screws are tightened to the torque values specified in the user manual to prevent loose connections.
