Schneider Modicon Premium TSXAEY800C Analog Input Module

SKU TSXAEY800C

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Schneider Electric

  • Product No.: TSXAEY800C

  • Country of origin:France

  • Product Type: Analog Modules

  • Payment: T/T, Western Union

  • Weight: 940g

  • Dimensions: 18,00cm x 26,00cm x 5,50cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The TSXAEY800C is a Modicon Premium analog input module designed to provide high-precision data acquisition for industrial control systems. This module features 8 multirange analog inputs with a common point, allowing for versatile sensor interfacing across various signal standards. Engineered for the Modicon Premium platform, the TSXAEY800C ensures reliable, consistent data conversion, making it a critical component for monitoring processes, temperature, pressure, and other variable industrial parameters.

Features

  • 8 multirange analog inputs
  • Common point input configuration
  • Designed for the Modicon Premium automation platform
  • Versatile sensor and signal compatibility
  • Reliable data conversion for industrial monitoring
  • Compact design for rack-mount integration

Applications

  • Process automation and monitoring
  • Data acquisition for SCADA systems
  • Industrial instrumentation and sensor interfacing
  • Environmental parameter tracking
  • Precision control of analog feedback loops

Technical Specifications

Specification Details
Manufacturer Schneider Electric
Range Modicon Premium
Product Type Analog modules
Number of Inputs 8
Input Type Multirange (Common point)
Dimensions 18.00 x 26.00 x 5.50 cm
Weight 0.94 kg
Commodity Code 85371099
Product Status Phase-Out

Installation Guidelines

  • Mounting: Insert the module into the Modicon Premium rack, ensuring the backplane connector is fully engaged and the module is locked into position.
  • Wiring: Use shielded, twisted-pair cables to connect analog sensors to the input terminals to minimize noise interference. Maintain proper segregation between analog signal wiring and high-power cables.
  • Grounding: Establish a reliable common point connection as required by the specific application architecture to ensure accurate signal referencing.
  • Calibration: Verify input scaling and range configuration within the PLC programming environment to match the specific signal output of connected sensors.
  • Environment: Ensure the installation environment is free from excessive electromagnetic noise and vibration to maintain measurement accuracy.

FAQ

How many analog inputs does the TSXAEY800C module support?
This module features 8 analog input channels.

What is the input configuration of this module?
It features multirange analog inputs with a common point.

Which automation range is this module compatible with?
It is designed for the Schneider Electric Modicon Premium range.

What is the current lifecycle status of the TSXAEY800C?
The module is currently classified in the Phase-Out product lifecycle stage.
