Schneider Modicon X80 BMXDDM16022H Discrete I/O Module

SKU BMXDDM16022H

In stock
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: Schneider Electric
  • Product No.: BMXDDM16022H
  • Origin France
  • Product Type: Digital Modules
  • Payment: T/T, Western Union
  • Weight: 0.16 kg
  • Dimensions: 12cm x 11cm x 5,5cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Digital Modules
Quantity
Call sales Contact

Product Description

Description

The BMXDDM16022H is a Modicon X80 series discrete I/O module designed for operation in harsh industrial environments. This module features 8 inputs (24V DC) and 8 solid-state outputs, providing reliable signal processing for automated control systems. As part of the Modicon X80 platform, it ensures seamless integration within Modicon M340 architectures, offering robust performance for applications requiring high availability and environmental durability.

Features

  • Designed for use in harsh environmental conditions
  • Equipped with 8 discrete inputs (24V DC)
  • Equipped with 8 discrete solid-state outputs
  • Fully compatible with the Modicon X80 I/O platform
  • Compact, lightweight design for high-density cabinet installations

Applications

  • Harsh environment automation control
  • Process automation and monitoring
  • Distributed I/O systems
  • Infrastructure and water treatment control
  • Material handling and packaging lines

Technical Specifications

Feature Specification
Manufacturer Schneider Electric
Brand Schneider Electric
Range Modicon X80
Product Type Digital module
Product Phase Active
Inputs 8 x 24V DC
Outputs 8 x Solid-state
Weight 0.16 kg
Dimensions 12.00 cm x 11.00 cm x 5.50 cm
Commodity Code 85389091
Export Control Regulations (ECCN) N

Installation Guidelines

  • Mounting: Designed for installation on standard Modicon X80 racks.
  • Environment: Specifically engineered for "harsh" environments; ensure ambient conditions remain within the specified operational limits for temperature and humidity.
  • Wiring: Ensure all 24V DC input and solid-state output connections are secured according to the module terminal diagram to prevent intermittent signals.
  • Grounding: Maintain proper grounding of the rack assembly to ensure electromagnetic compatibility and protection against electrical noise.
  • Maintenance: Regularly inspect terminal blocks for signs of oxidation or wear, particularly in high-vibration or corrosive environments.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What are the input and output configurations for this module?
This module features 8 discrete inputs rated for 24V DC and 8 solid-state discrete outputs.
Is the BMXDDM16022H suitable for extreme environments?
Yes, this module is specifically designated for harsh conditions within the Modicon X80 range.
What is the physical weight of this module?
The module weighs 0.16 kg.
Does this module support the Modicon M340 platform?
Yes, it is fully compatible with the Modicon M340 and the broader Modicon X80 I/O architecture.
Reviews

More from this brand

Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
170XTS00200Schneider 170XTS00200 Modicon Momentum/Quantum Spring Terminal Block
Schneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
TSXP57303AMCSchneider TSXP57303AMC Modicon Premium Double-Format PL7 Processor
Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
170ADM69051Schneider 170ADM69051 Modicon Momentum Discrete I/O Base (10I/8O)
Schneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive
ATV212WU22N4CSchneider Electric ATV212WU22N4C Altivar 212 Variable Frequency Drive

BMXDDM16022H

Stock & lead time on request

Call
  • BMXDDM16022H
1 1

Schneider Modicon X80 BMXDDM16022H Discrete I/O Module
