Siemens 6AV3535-1FA01-0AX0 Coros OP35 Operator Panel

SKU 6AV3535-1FA01-0AX0

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV3535-1FA01-0AX0
Country of origin:Germany
Product Type: Operator Panels
Barcode: 85371091
Payment: T/T, Western Union
Weight: 6350g
Dimensions: 48.30 x 30.50 x 10.20 cm
Shipping port: Xiamen
Warranty: 12 months

Description

This Siemens 6AV3535-1FA01-0AX0 is an OP 35 Operator Panel from the Coros HMI series, designed for process monitoring and control in industrial automation systems. The unit features a monochrome LC display with pixel graphics for clear data visualization. It provides extensive connectivity through four integrated interfaces, including TTY/V.24, X.27/TTY, and MPI/PPI. This model is supplied without a direct keypad, offering flexibility for custom mounting and integration into control cabinets or existing operator stations. As an obsolete part, it serves as a direct replacement for maintaining legacy systems.

Features

Monochrome Liquid Crystal Display (LCD) with pixel graphics.
Four integrated communication interfaces for versatile connectivity.
Supports TTY/V.24, X.27/TTY, and MPI/PPI protocols.
Designed without an integrated keypad for flexible system design.
Part of the Siemens Coros HMI product family.

Applications

Machine control and process visualization.
Legacy system maintenance and spare parts replacement.
Industrial production lines.
Data entry and monitoring stations in manufacturing environments.

Technical Specifications

Specification	Value
Brand	Siemens
Model Number	6AV3535-1FA01-0AX0
Product Series	Coros HMI, OP35 Series
Product Type	Operator Panel
Display Type	Monochrome LC Display (Pixel Graphics)
Integrated Interfaces	2 x TTY/V.24, 1 x X.27/TTY, 1 x MPI/PPI
Keypad	Not included
Product Lifecycle Status	Obsolete
Successor Part Number	6AV3535-1FA01-1AX0
Shipping Weight	6.35 kg
Package Dimensions (Source)	48.30 x 30.50 x 10.20 cm
Commodity Code	85371091
ECCN	N
Country of Origin	Germany (Estimated)

Installation Guidelines

CRITICAL WARNING: This product is obsolete. Before installation, verify complete compatibility with the existing control system, including software, hardware, and communication protocols. Incorrect integration can lead to system malfunction or equipment damage.

1 De-energize the entire control cabinet and associated machinery. Follow all local Lockout/Tagout (LOTO) procedures to prevent accidental startup.
2 Prepare the panel cutout according to the device's mechanical dimensions. Ensure the mounting surface is clean, flat, and provides adequate support.
3 Secure the operator panel into the cutout using the appropriate mounting hardware. Ensure a proper seal is achieved if the application requires a specific IP rating.
4 Connect the power supply wiring to the designated terminals. Verify the voltage matches the panel's requirements. Connect the functional earth (FE) or protective earth (PE) terminal to the cabinet's ground bus.
5 Connect the communication cables (TTY, MPI/PPI) to the corresponding ports. Route cables away from high-voltage lines to minimize electromagnetic interference. Use shielded cables where specified.
6 After all connections are verified, remove LOTO devices and re-energize the system. Proceed with software configuration and communication testing.

FAQ

What type of display does the 6AV3535-1FA01-0AX0 panel have?

It features a monochrome LC display with pixel graphics for clear visualization of operational data.

What communication interfaces are available on this operator panel?

The panel is equipped with four integrated interfaces: two TTY/V.24 ports, one X.27/TTY port, and one MPI/PPI port.

Is this an active Siemens product?

No, the 6AV3535-1FA01-0AX0 is an obsolete product. The designated successor part number is 6AV3535-1FA01-1AX0.

Does this model include an integrated keypad?

No, this version is supplied without a direct keypad, which allows for custom integration with external input devices or mounting in specific enclosures.
