Siemens 6AV6643-0CB01-1AX1 SIMATIC MP 277-8 Multi Panel

SKU 6AV6643-0CB01-1AX1

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Siemens

  • Product No.: 6AV6643-0CB01-1AX1

  • Country of origin:Germany

  • Product Type: Multi Panel

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 1640g

  • Dimensions: 25.1 x 19 x 6.6 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The Siemens 6AV6643-0CB01-1AX1 Multi Panel is a high-performance Human Machine Interface (HMI) designed for industrial environments. This unit, part of the SIMATIC MP 277 8” Touch series, features a 7.5-inch TFT color display capable of rendering 65,536 colors with a resolution of 640 x 480 pixels. It is equipped with 128 MB of main memory and 6 MB of user-configurable memory, supporting complex automation applications configured via WinCC flexible 2005. The 6AV6643-0CB01-1AX1 provides reliable system monitoring and control, offering a backlighting Mean Time Between Failure (MTBF) of up to 50,000 hours at 25 degC. It supports Ethernet communication and is built to Siemens' quality standards for robust operation, even in harsh conditions. While currently active, this model is marked for delivery phase-out, with alternative models available within the SIMATIC product family.

Features

  • 7.5-inch TFT color display with 65,536 colors
  • 640 x 480 pixel display resolution
  • 128 MB main memory with 6 MB user memory
  • Backlighting MTBF of 50,000 hours at 25 degC
  • Supports configuration with WinCC flexible 2005
  • Integrated Ethernet communication service
  • Robust design for industrial applications

Applications

  • Manufacturing process monitoring and control
  • Machine-level HMI operations
  • Industrial automation systems requiring visual feedback
  • Process automation control panels

Technical Specifications

Parameter Value
Model Number 6AV6643-0CB01-1AX1
Module Type Multi Panel
Manufacturer Siemens
Condition Brand New
Product Series SIMATIC MP 277 8” Touch series
Lead Time In Stock
Shipping Weight 1.64 kg
HS Code 8537101190
Package Dimensions (Calculated) 25.1 x 19 x 6.6 cm
Minimum Order Quantity (MOQ) 1
Country of Origin GERMANY
System Compatibility PLC
Product Status Active (Delivery Phase-Out)
Communication Service Ethernet router
Display Type TFT color
Display Size 7.5-inch
Display Colors 65,536 colors
Resolution 640 x 480 pixels
Backlighting MTBF 50,000 hours at 25 degC
Main Memory 128 MB
User Memory 6 MB
Configuration Software WinCC flexible 2005

Installation Guidelines

  1. Ensure all power to the control system is de-energized before beginning installation.
  2. Mount the Multi Panel securely into a prepared panel cutout, ensuring proper sealing to maintain environmental ratings.
  3. Connect the Ethernet communication cable to the designated port on the panel and to the network infrastructure.
  4. Route all cables to prevent strain, interference, and damage, securing them with appropriate cable management solutions.
  5. Verify all connections for correct polarity and secure termination.
  6. Restore power to the system and perform functional tests to confirm proper operation and communication.

FAQ

What is the display size and resolution of the 6AV6643-0CB01-1AX1?
The panel features a 7.5-inch TFT color display with a resolution of 640 x 480 pixels.

Which software is used to configure this Multi Panel?
The 6AV6643-0CB01-1AX1 is configured using WinCC flexible 2005 software.

What type of communication does this panel support?
It supports communication via an Ethernet router service.

What is the expected lifespan of the display backlighting?
The backlighting has a Mean Time Between Failure (MTBF) of up to 50,000 hours at 25 degC.

Is the 6AV6643-0CB01-1AX1 still an active product?
Yes, it is currently active, but it is marked for delivery phase-out, with alternative models available.
