Siemens 6AV7704-2DC10-0AD0 SIMATIC Panel PC 870

Description

The Siemens 6AV7704-2DC10-0AD0 is a SIMATIC Panel PC 870 designed for demanding industrial environments requiring robust performance and reliable operation. This unit features a 15.1-inch color TFT display with integrated touch functionality, providing clear visuals and intuitive interaction for operators. Equipped with a Pentium III 1.26 GHz processor and 256 MB RAM, the 6AV7704-2DC10-0AD0 supports efficient data processing for a range of industrial applications. The system includes a 30 GB EIDE hard disk drive and a CD-ROM for media access and software installation. It operates on 230V mains power and comes supplied with a Euro plug power cable. Pre-installed with Windows 2000 in multiple languages (English, German, French, Italian, and Spanish), this panel PC is suitable for international production facilities, ensuring compatibility with existing automation systems and seamless integration into production processes.

Features

• 15.1-inch Color TFT Display with Touch Functionality
• Pentium III 1.26 GHz Processor
• 256 MB RAM
• 30 GB EIDE Hard Disk Drive
• Integrated CD-ROM Drive
• Pre-installed Windows 2000 Multi-Language Operating System
• 230V Mains Power Operation with Euro Plug Cable
• Designed for Demanding Industrial Environments

Applications

The Siemens SIMATIC Panel PC 870 is suitable for deployment in various industrial settings, including:

• Machine control and visualization
• Process monitoring and data acquisition
• Operator interface for automation systems
• Production line management
• Industrial data processing and HMI applications in international facilities

Technical Specifications

Installation Guidelines

1. De-energize System: Ensure all power to the installation area and associated equipment is completely disconnected and locked out before beginning installation.
2. Mounting: Securely mount the panel PC into a prepared panel cutout. Ensure proper clearance for ventilation and cable routing.
3. Power Connection: Connect the supplied Euro plug power cable to a 230V mains power source. Verify correct voltage before applying power.
4. Peripheral Connections: Connect any necessary industrial peripherals, such as keyboards, mice, or communication cables, to the appropriate ports.
5. Grounding: Ensure the panel PC chassis is properly grounded to the industrial enclosure's protective earth for safety and EMI reduction.
6. Cable Management: Route all cables to prevent strain, interference, and damage. Use cable ties and conduits where appropriate.
7. Environmental Considerations: Confirm the operating environment (temperature, humidity, vibration) is within the specified limits for industrial panel PCs to ensure reliable operation.
8. Power Up: After all connections are secure and verified, restore power to the system and verify proper boot-up and display functionality.
