Siemens 6ES7151-1CA00-3BL0 SIMATIC ET 200S Compact Interface Module

SKU 6ES7151-1CA00-3BL0

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Siemens

  • Product No.: 6ES7151-1CA00-3BL0

  • Country of origin:Germany

  • Product Type: PLC Interface Modules

  • Barcode: 8537101190

  • Payment: T/T, Western Union

  • Weight: 950g

  • Dimensions: 12.7 cm x 10.2 cm x 7.6 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

This is the Siemens SIMATIC ET 200S compact interface module, model 6ES7151-1CA00-3BL0 (IM151-1). It functions as a sophisticated interface for distributed I/O systems, integrating 16 digital inputs and 16 digital outputs within a single compact unit. Engineered for reliable 24V DC operation and a swift 3ms response time, this module is well-suited for high-speed control applications. It provides full compatibility with the PROFIBUS DP network protocol and allows for system expansion to meet specific project requirements.

Features

  • ■Integrated 16 digital inputs and 16 digital outputs.
  • ■Operates on a standard 24V DC industrial power supply.
  • ■Fast 3ms response time suitable for time-critical processes.
  • ■Supports system expansion with up to 12 additional ET 200S modules.
  • ■Communicates via the PROFIBUS DP network protocol.
  • ■Compact housing for efficient use of control cabinet space.

Applications

This module is designed for use in distributed automation systems across various industries, including:

  • ■Automotive manufacturing and assembly lines
  • ■Packaging and material handling systems
  • ■Process control in food and beverage
  • ■General machine building and factory automation

Technical Specifications

Specification Value
Model Number 6ES7151-1CA00-3BL0
Alternate Model IM151-1
Series SIMATIC ET 200S
Module Type Compact Interface Module
Manufacturer Siemens
Country of Origin Germany
Supply Voltage 24V DC
Digital Inputs 16
Digital Outputs 16
Response Time 3 ms
Communication Protocol PROFIBUS DP
Maximum Expansion Modules 12
Product Weight 0.293 kg
Shipping Weight 0.95 kg
Product Dimensions (H x W x D) 12.7 cm x 10.2 cm x 7.6 cm
Package Dimensions (Calculated) 18 cm x 15 cm x 12 cm
HS Code 8537101190
Product Lifecycle Active

Installation Guidelines

CRITICAL WARNING: Hazardous voltages can cause severe injury or death. Disconnect and lock out all power sources before installation or maintenance. Work should only be performed by qualified personnel. Use appropriate personal protective equipment (PPE) and follow all site-specific safety procedures.
  1. 1 Ensure the control cabinet is de-energized and verified to be in a zero-energy state.
  2. 2 Securely mount the module onto a standard 35mm DIN rail inside the enclosure, ensuring proper grounding through the rail connection.
  3. 3 Connect the 24V DC power supply to the designated terminals, observing correct polarity.
  4. 4 Terminate the PROFIBUS DP communication cable using the appropriate connectors. Ensure proper shielding and termination resistor placement as required by the network topology.
  5. 5 Connect sensor and actuator wiring to the respective digital input and output terminals.
  6. 6 After verifying all connections are secure and correct, remove the lockout/tagout devices and re-energize the system for commissioning.

FAQ

What is the I/O count of the 6ES7151-1CA00-3BL0 module?
This module features 16 integrated digital inputs and 16 integrated digital outputs.

What communication protocol does this interface module use?
It is designed for use on a PROFIBUS DP industrial communication network.

How many expansion modules can be connected to this unit?
The system can be expanded by connecting up to 12 additional ET 200S I/O modules.

What is the required power supply for this module?
The module requires a nominal 24V DC power supply for operation.

View all FAQs →

Siemens 6ES7151-1CA00-3BL0
Siemens 6ES7151-1CA00-3BL0
Siemens 6ES7151-1CA00-3BL0
