Description
The Siemens 6ES7195-7HB00-0XA0 is a bus module designed for use within the SIMATIC ET 200M distributed I/O system. This passive component provides the mechanical and electrical connection for up to two 40 mm wide I/O modules, integrating them into the ET 200M station's backplane bus. Its design facilitates the removal and insertion of I/O modules during operation (hot-swapping) without interrupting the system, which is critical for maintaining uptime in continuous process applications.
Features
- Accommodates two I/O modules with a width of 40 mm each.
- Enables hot-swapping of I/O modules without system interruption.
- Provides a secure mechanical and electrical connection to the ET 200M backplane.
- Compact design for efficient use of cabinet space.
- Designed for tool-free handling, simplifying installation and maintenance procedures.
Applications
- Decentralized automation systems
- Process control and monitoring
- Manufacturing and assembly lines
- Material handling and logistics
- Building automation systems
Technical Specifications
| Specification |
Value |
| Manufacturer |
Siemens |
| Part Number |
6ES7195-7HB00-0XA0 |
| Product Family |
SIMATIC DP |
| System Compatibility |
ET 200M Distributed I/O System |
| Module Type |
Bus Module |
| I/O Module Capacity |
2 modules (40 mm width each) |
| Shipping Weight |
0.1 kg |
| Package Dimensions (Calculated) |
9.7 x 9.3 x 6.1 cm |
| Country of Origin |
Germany |
| HS Code |
8537101190 |
Installation Guidelines
CRITICAL WARNING: Always de-energize the ET 200M station and follow all Lockout/Tagout (LOTO) procedures before installing or removing bus modules. Failure to disconnect power can result in electric shock, equipment damage, and unintended machine operation.
-
1
Verify that the ET 200M station, including the interface module and power supply, is completely de-energized and secured against accidental restart.
-
2
Position the bus module on the ET 200M mounting rail. Align the hooks on the rear of the module with the rail profile and press down firmly until it clicks securely into place.
-
3
Install adjacent bus modules as required, ensuring they are seated correctly and interlocked with each other to form a continuous backplane bus.
-
4
Once the bus modules are installed, insert the corresponding I/O modules into the slots. Slide them in until they are fully seated and the locking mechanism engages.
-
5
After all modules are installed and wired, remove LOTO devices and restore power to the station according to site procedures. Verify system communication and I/O status.
