Siemens 6ES7647-7AK30-0RA0 SIMATIC Microbox PC 427B

Description

The Siemens 6ES7647-7AK30-0RA0 is a SIMATIC Microbox PC 427B designed for robust industrial automation applications. This compact industrial PC features a Pentium M 1.4 GHz processor with a 400 MHz FSB and 2 MB SLC. It is equipped with 1 GByte DDR2 533 SODIMM memory (configured as one 1 GB module) and a 4 GB Compact-Flash drive, which is both replaceable and accessible for maintenance. The unit supports PROFIBUS DP 12 for integration into industrial communication networks. It comes with Windows XP Embedded preinstalled, though the embedded Windows software is delivered separately.

Features

• Processor: Pentium M 1.4 GHz, 400 MHz FSB, 2 MB SLC
• Memory: 1 GByte DDR2 533 SODIMM (1 x 1 GB)
• Storage: 4 GB Compact-Flash (replaceable, accessible)
• Communication Interface: PROFIBUS DP 12
• Operating System: Windows XP Embedded preinstalled (software delivered separately)
• Hardware Extension: Without HW extension

Applications

The Siemens SIMATIC Microbox PC 427B is suitable for a range of industrial applications requiring reliable and compact computing solutions, including:

• Machine control and data acquisition
• Process visualization and Human-Machine Interface (HMI) tasks
• Distributed control system (DCS) integration
• Industrial communication and gateway functions
• Embedded control systems in manufacturing and process industries
