Siemens

Siemens 6ES7660-5YF68-8AL0 SIMATIC PCS 7 Industrial Workstation

SKU 6ES7660-5YF68-8AL0

In stock
  • 12-month warranty
  • Free returns within 30 days

  • Manufacturer: Siemens

  • Product No.: 6ES7660-5YF68-8AL0

  • Country of origin:Germany

  • Product Type: Industrial Rack PC

  • Barcode: 85371091

  • Payment: T/T, Western Union

  • Weight: 15g

  • Dimensions: 60 x 55 x 20 cm

  • Shipping port: Xiamen

  • Warranty: 12 months

Description

The Siemens 6ES7660-5YF68-8AL0 is a SIMATIC PCS 7 Industrial Workstation, model IPC647D, configured as a high-performance rack PC. This unit is housed in a 19-inch, 2U (2HE) chassis and is powered by an Intel Xeon E3-1268LV3 processor. It is equipped with 16 GB of DDR3 SDRAM and a 1 TB RAID1 storage configuration using two hot-swappable SATA hard drives for data mirroring. Designed for demanding industrial environments, it includes integrated temperature and fan monitoring, a watchdog timer, and a card retainer for enhanced reliability. The workstation provides extensive connectivity with multiple USB 3.0, Gigabit LAN, and display ports.

Features

  • 19-inch, 2U rack-mountable chassis for standard industrial cabinets.
  • Intel Xeon E3-1268LV3 quad-core processor (4C/8T, 2.3 GHz).
  • 1 TB RAID1 configuration (2x 1 TB SATA HDD) for data mirroring.
  • Hot-swappable drives mounted in a front-accessible removable frame.
  • 16 GB DDR3 SDRAM in a dual-channel configuration.
  • Integrated Industrial Ethernet via CP1623 module.
  • Pre-installed Windows 7 Ultimate 64-bit MUI.
  • Built-in system diagnostics including temperature/fan monitoring and watchdog.

Applications

  • Process visualization and HMI operator stations.
  • SCADA system servers and clients.
  • Industrial data acquisition and logging platforms.
  • Engineering and configuration workstations in a PCS 7 environment.

Technical Specifications

Specification Value
Manufacturer Siemens
Product Series SIMATIC PCS 7 / SIMATIC Rack PC
Model IPC647D
Part Number 6ES7660-5YF68-8AL0
Form Factor Rack PC, 19", 2HE
Processor Intel Xeon E3-1268LV3 (4C/8T, 2.3 GHz, 8 MB Cache, TB, VT-D, AMT)
Memory (RAM) 16 GB DDR3 SDRAM (2x 8 GB), Dual Channel
Storage RAID1, 1 TB (2x 1 TB HDD SATA, Data Mirroring)
Storage Feature Hot-swap, in removable front frame
Optical Drive DVD +/-RW (Slim)
Expansion Slots 2x PCI, 2x PCIe x16 (8 Lane)
Operating System Windows 7 Ultimate, 64 Bit, MUI (EN/DE/FR/IT/ES/CN)
Power Supply 100/240V AC Industrial Power Supply Unit with NAMUR
Power Cable Not included
Shipping Weight 15.00 kg
Package Dimensions (Calculated) 60 x 55 x 20 cm
Country of Origin Germany (Estimate)
Product Lifecycle Status Phase-Out

Connections and Interfaces

Location Interface Quantity
Rear Panel Gigabit LAN (RJ45) 2
DVI-I 1
DisplayPort 2
COM (Serial) 1
PS/2 (Keyboard/Mouse) 2
USB 3.0 2
USB 2.0 2
Front Panel USB 3.0 1
USB 2.0 1
Internal USB 3.0 1
Expansion Card Industrial Ethernet (CP1623) 1

Installation Guidelines

CRITICAL WARNING: Disconnect all power sources from the rack cabinet and follow Lockout/Tagout (LOTO) procedures before installation. This equipment operates at hazardous voltages. Installation must be performed by qualified personnel only.
  1. 1 Verify that 2U (2HE) of vertical space is available in the 19-inch rack. Ensure adequate clearance for airflow at the front and rear of the unit.
  2. 2 Slide the IPC into the rack and secure it to the vertical rails using all four mounting points with appropriate cage nuts and screws.
  3. 3 Connect a protective earth (PE) conductor to the designated grounding point on the chassis to ensure electrical safety.
  4. 4 Connect peripherals such as monitors (DVI/DisplayPort), keyboard/mouse (PS/2 or USB), and any required serial devices.
  5. 5 Connect network cables to the Gigabit LAN and Industrial Ethernet ports as required by the application.
  6. 6 Connect a suitable power supply cable (not included) to the power supply unit and to the main power source. After verifying all connections, remove LOTO and energize the unit.

FAQ

What processor is included in the 6ES7660-5YF68-8AL0?
This industrial workstation is equipped with an Intel Xeon E3-1268LV3 processor, which features 4 cores, 8 threads, and a base clock speed of 2.3 GHz.

What is the storage configuration of this SIMATIC IPC?
It is configured with a 1 TB RAID1 array for data mirroring. This consists of two 1 TB SATA hard disk drives installed in a front-accessible, hot-swappable frame.

Which operating system is pre-installed on this device?
The unit comes with Windows 7 Ultimate (64-bit) pre-installed. It includes a Multi-Language User Interface (MUI) with support for English, German, French, Italian, Spanish, and Chinese.

Does this industrial PC come with a power cable?
No, the product description explicitly states it is supplied 'WITHOUT POWER SUPPLY CABLE'. A regionally appropriate power cable must be sourced separately.

What video outputs are available on the IPC647D?
The workstation provides three video outputs on the rear panel: one DVI-I port and two DisplayPort interfaces, allowing for multi-monitor setups.
