Siemens 6GK5308-2GG10-2AA2 SCALANCE X308-2M Managed Industrial Ethernet Switch

SKU 6GK5308-2GG10-2AA2

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6GK5308-2GG10-2AA2
Country of origin:Germany
Product Type: Ethernet Switch
Barcode: 85389091
Payment: T/T, Western Union
Weight: 900g
Dimensions: 12.0 cm x 12.4 cm x 12.5 cm
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6GK5308-2GG10-2AA2 is a SCALANCE X308-2M compact managed Industrial Ethernet switch designed for machine-level networking and control cabinet installation. It provides a flexible port configuration with four fixed 10/100/1000 Mbit/s RJ45 ports and two slots for 2-port media modules, allowing for either electrical or optical connections at 100/1000 Mbit/s. As a PROFINET IO device with an integrated redundancy manager, this switch ensures high network availability and seamless integration into Siemens automation environments. The unit includes a C-PLUG in the scope of delivery for simple configuration backup and device replacement.

Features

■ Managed Layer 2 switching capabilities for network control.
■ Integrated redundancy manager to enhance network uptime.
■ Functions as a PROFINET IO device for diagnostics and system integration.
■ Supports standard office IT protocols including RSTP, VLAN, and IGMP.
■ Equipped with LED diagnostics, an error signaling contact, and a select/set button for on-site management.
■ Includes a C-PLUG removable memory module for configuration storage.

Applications

■ Factory and plant automation networks requiring high availability.
■ Machine-level data aggregation and communication.
■ Integration of PROFINET-enabled devices into a structured Ethernet network.
■ Control systems requiring network segmentation via VLANs.

Technical Specifications

Product Identification
Manufacturer	Siemens
Product Series	SCALANCE X-300
Model Number	SCALANCE X308-2M
Part Number	6GK5308-2GG10-2AA2
Product Type	Managed Industrial Ethernet Switch
Interfaces
Electrical Ports	4 x RJ45
Electrical Port Speed	10/100/1000 Mbit/s
Media Module Slots	2 (for 2-port media modules, electrical or optical)
Media Module Speed	100/1000 Mbit/s
Functionality
Supported Protocols	PROFINET IO, RSTP, VLAN, IGMP
Included Accessories	C-PLUG
Logistics and Compliance
Product Lifecycle Status	Phase-Out
Shipping Weight	0.90 kg
Package Dimensions (Calculated)	12.0 cm x 12.4 cm x 12.5 cm
Commodity Code	85389091
ECCN	5A002
Country of Origin	Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: Electrical Hazard. Installation must be performed by qualified personnel only. Disconnect and lock out all power sources before installation or maintenance to prevent electric shock or equipment damage.

1 De-energize Panel: Verify the control cabinet is completely de-energized and follow all applicable Lockout/Tagout (LOTO) procedures before beginning work.
2 Mount Switch: Securely mount the SCALANCE switch onto a standard 35mm DIN rail within the enclosure, ensuring adequate clearance for ventilation and cable access.
3 Connect Functional Ground: Connect the functional earth (FE) terminal on the switch to the cabinet's equipotential bonding rail using a low-impedance conductor.
4 Connect Power Supply: Connect the specified DC power source to the power supply terminal block, observing correct polarity. If redundant power supplies are used, connect both.
5 Connect Network Cables: Connect shielded Ethernet cables to the RJ45 ports. If using media modules, install them into the slots and connect the corresponding cables. Ensure proper cable routing and strain relief.
6 Power On and Verify: After ensuring all connections are secure, re-energize the cabinet. Observe the device LEDs to confirm power status, network link, and activity.

FAQ

What exactly is the port layout on this managed switch?

The switch features four fixed 10/100/1000 Mbit/s RJ45 ports and two expansion slots that accept 2-port electrical or optical media modules for up to four additional ports.

What is the primary function of the included C-PLUG accessory?

The C-PLUG is a removable memory module that automatically saves all network and switch configuration settings, allowing the switch to be replaced quickly without needing a computer.

Does this SCALANCE switch provide network redundancy protocols?

Yes, it features an integrated network redundancy manager and fully supports standard network uptime protocols including RSTP, VLANs, and PROFINET IO mechanisms.
