Siemens 6SE7016-1EA11-Z SIMOVERT MASTERDRIVES FC Compact Unit

Description

The 6SE7016-1EA11-Z is a SIMOVERT MASTERDRIVES FC (Frequency Converter) compact unit designed for efficient motor control in industrial automation. This base drive unit is optimized for 3-phase supply voltages of 380-460 V AC at 50/60 Hz and delivers a power output of 2.2 kW with a nominal current of 6.1 A. Housed in an IP20-rated enclosure, the unit is intended for installation within protected electrical control cabinets. The 6SE7016-1EA11-Z serves as a modular foundation, allowing for the integration of specialized options to meet the precise requirements of your specific drive application.

Features

• Drive Type: Frequency Converter (FC)
• Power Rating: 2.2 kW
• Current Rating: 6.1 A nominal output
• Input Voltage: 3-phase 380-460 V AC, 50/60 Hz
• Design: Compact unit with IP20 protection
• Modular Architecture: Base drive configuration for field-expandable functionality

Applications

• Material handling and conveyor systems
• Industrial pump and fan control
• Automated manufacturing processes
• General motion control in industrial production lines

Technical Specifications

Installation Guidelines

• Mounting: Install in a vertical position inside an IP20-compliant cabinet. Maintain necessary clearances above and below the device to ensure adequate airflow and thermal cooling.
• Environment: The operating environment must be kept free of conductive dust, moisture, and corrosive substances to ensure long-term reliability of the internal electronics.
• Wiring: Connect 3-phase AC input to the primary power terminals. Use shielded motor cables to help reduce potential electromagnetic interference (EMI) during operation.
• Grounding: Maintain a secure connection to the cabinet chassis ground to ensure safety and improve the immunity of the drive to electrical noise.
• Cooling: Ensure that internal cabinet fans are fully operational and that the drive's air vents remain unobstructed.
