Siemens SIMATIC IPC677D 6AV7260-1GY31-0BX6 Panel PC

SKU 6AV7260-1GY31-0BX6

In stock

12-month warranty
Free returns within 30 days

Manufacturer: Siemens
Product No.: 6AV7260-1GY31-0BX6
Country of origin:Germany
Product Type: Panel PC
Barcode: 85371098
Payment: T/T, Western Union
Weight: 17g
Dimensions: 58 x 48 x 25 cm (Estimate)
Shipping port: Xiamen
Warranty: 12 months

Description

The Siemens 6AV7260-1GY31-0BX6 is a SIMATIC IPC677D Panel PC designed for industrial control and visualization applications. This unit integrates a 19-inch touchscreen display with a native resolution of 1366 x 768 pixels into a robust industrial computer chassis. It is equipped with comprehensive connectivity, including dual 10/100/1000 Mbit/s Ethernet ports, four rear USB 3.0 ports, and a convenient front-mounted USB port. For system reliability and data integrity, the IPC677D features an onboard RAID controller and integrated monitoring for watchdog, temperature, and fan status.

Features

19-inch color touchscreen display
Display resolution of 1366 x 768 pixels
Dual Gigabit Ethernet interfaces for network redundancy or separation
Four rear-mounted USB 3.0 ports for high-speed peripherals
One front-accessible USB port for temporary device connection
Integrated hardware RAID controller for enhanced data protection
Built-in system monitoring for watchdog timer, temperature, and fan speed
One standard RS-232 serial port (COM1)

Applications

Human-Machine Interface (HMI) for process control
SCADA client stations in manufacturing and utility environments
Machine-level data acquisition and logging
Industrial control room operator stations
Production line monitoring and diagnostics

Technical Specifications

Specification	Value
Manufacturer	Siemens
Part Number	6AV7260-1GY31-0BX6
Product Series	SIMATIC IPC677D
Product Type	Panel PC
Display Size	19-inch
Display Type	Touchscreen
Resolution	1366 x 768
Ethernet Ports	2 x 10/100/1000 Mbit/s
USB Ports	4 x USB 3.0 (Rear), 1 x USB (Front)
Serial Port	1 x COM1 (RS-232)
System Monitoring	Watchdog, Temperature, Fan
Storage Controller	Onboard RAID Controller
Product Lifecycle Status	Phase-Out
Shipping Weight	17.00 kg
Commodity Code	85371098
Country of Origin	Germany (Estimate)
Package Dimensions (Calculated)	58 x 48 x 25 cm (Estimate)

Installation Guidelines

CRITICAL WARNING: Electrical hazard. Installation must be performed by qualified personnel only. De-energize the enclosure and apply Lockout/Tagout (LOTO) procedures before commencing any work. Failure to comply can result in severe injury or death.

1 Verify the panel cutout dimensions match the IPC677D installation requirements. Ensure the mounting surface is flat, clean, and capable of supporting the unit's weight.
2 Insert the Panel PC into the cutout from the front of the enclosure. Secure it from the rear using all provided mounting clamps, tightening them evenly to the manufacturer's specified torque to ensure a proper seal.
3 Connect a low-impedance protective earth (PE) conductor to the designated grounding terminal on the chassis. This is critical for operator safety and electromagnetic compatibility (EMC).
4 Connect the main power supply to the unit's power input connector. Ensure the source voltage matches the rating specified on the device label.
5 Connect Ethernet, USB, and serial communication cables as required by the application. Use shielded cables for all data connections and ensure proper shield termination to minimize noise interference.

FAQ

What are the screen specifications for the 6AV7260-1GY31-0BX6?

This Panel PC features a 19-inch touchscreen display with a native resolution of 1366 x 768 pixels.

What networking interfaces are available on this SIMATIC IPC?

The unit is equipped with two 10/100/1000 Mbit/s Ethernet ports, allowing for high-speed network communication or network segmentation.

Does this unit include features for system reliability?

Yes, it includes an onboard RAID controller for data redundancy and integrated hardware monitoring for system temperature, fan status, and a watchdog timer.

How many USB ports does this Panel PC have?

It has a total of five USB ports: four high-speed USB 3.0 ports on the rear and one conveniently located USB port on the front of the unit.

What is the product lifecycle status of this model?

The 6AV7260-1GY31-0BX6 is designated as a 'Phase-Out' product by the manufacturer, indicating it is approaching the end of its production life.
