Omron NS8-TV01B-V2 NS Series HMI Touch Screen Terminal

Description

Designed for robust industrial automation control and machinery visualization, the Omron NS8-TV01B-V2 is a high-performance human-machine interface (HMI) terminal within the respected NS Series lineup. This operator interface is engineered to provide clear, real-time machine status and diagnostics directly on the plant floor. Featuring an 8.4-inch TFT color display with a high-efficiency LED backlight, the module enables precise touch response and sharp graphics for complex operator control screens.

Equipped with integrated Ethernet connectivity, the NS8-TV01B-V2 facilitates seamless data exchange with PLC systems and supervisory networks. It supports advanced utility functions, including direct ladder monitoring, which allows maintenance personnel to troubleshoot PLC program states directly from the HMI screen without requiring a separate laptop or programming software. The durable black case configuration is optimized for standard panel mounting in demanding manufacturing environments.

Features

• High-contrast 8.4-inch TFT color display with interactive touch panel controls.
• Integrated Ethernet port supporting high-speed controller communications and data sharing.
• Built-in ladder monitor function for efficient on-site PLC diagnostics and maintenance.
• Long-life LED backlight ensuring consistent brightness and reduced power consumption.
• Compact, space-saving mechanical profile with a durable black front bezel.

Applications

• Automotive assembly lines and robotic work cells.
• Packaging machinery and automated sorting systems.
• Water and wastewater treatment monitoring panels.
• Material handling systems and conveyor controls.
• Food and beverage processing equipment control interfaces.

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Panel Mounting: Install the terminal into a flat panel cutout with a panel thickness of 1.6 mm to 4.8 mm. Secure the unit using the provided mounting brackets to maintain protective sealing.
• Thermal Management: Ensure adequate clearance behind the unit for natural ventilation. Do not install the device in direct sunlight or adjacent to high-heat-generating industrial components.
• Power & Grounding: Use a dedicated, regulated 24 VDC power supply. Connect the functional ground terminal directly to a clean, low-impedance system earth ground to minimize electrical noise interference.
• Cable Routing: Separate communication cables (Ethernet/Serial) from high-voltage AC power lines to prevent signal corruption.
