Bently Nevada 330130-070-00-05 3300 XL Standard Extension Cable

Stokta sadece 7 adet kaldı

Üretici: Bently Nevada
Ürün No.: 330130-070-00-05
Menşei ülke:Amerika Birleşik Devletleri
Ürün Türü: 3300 XL Standard Extension Cable
Barkod: 8537101190
Ödeme: T/T, Western Union
Ağırlık: 240g
Boyutlar: 7000 mm x 7.24 mm x 7.24 mm (H x W x D)
Gönderim limanı: Xiamen
Garanti: 12 ay

Description

Option 070 (7.0 meters cable length), Option 00 (standard cable without armor), and Option 05 (CSA, ATEX, and IECEx hazardous area approvals) define the exact configuration of this 330130-070-00-05 3300 XL standard extension cable.

Unlike variants configured with Option 01 (armored cable) or Option 02 (with silicone connector protectors), this cable is unarmored to maintain a slim 3.7 mm outside diameter, facilitating routing through tight conduits. It connects an 8 mm proximity probe and a Proximitor sensor to form a complete 3300 XL non-contact eddy-current transducer system.

Features

Cable length: 7.0 meters (22.9 feet) for matching specific 7.0 m extension requirements in calibrated systems.
Cable option 00: Standard FEP insulated triaxial cable without protective stainless steel armor.
Connector design: Miniature gold-plated ClickLoc coaxial connectors (one male, one female) requiring finger-tight torque.
Environmental rating: Standard FEP jacket operating within broad temperature ranges.
Agency approval: Certified under option 05 for CSA, ATEX, and IECEx hazardous area installations.

Applications

Rotating machinery shaft vibration monitoring in petrochemical plants.
Axial position and thrust measurement on steam or gas turbines.
Industrial pumps, compressors, and gearboxes.
Connection between Bently Nevada 3300 XL 8 mm probes and Proximitor sensors.

Ordering Information

Option	Code on This SKU	Description
Orderable Part Number	330130-070-00-05	3300 XL Standard Extension Cable, unarmored, 7.0 m length, CSA/ATEX/IECEx approved
A - Cable Length Option	070	7.0 meters (22.9 feet)
B - Cable Option	00	Standard cable
C - Agency Approval Option	05	CSA, ATEX, IECEx Approvals

Technical Specifications

Parameter	Value
Manufacturer	Bently Nevada (Baker Hughes)
Part Number	330130-070-00-05
Cable Length	7.0 meters (22.9 feet)
Cable Type	Standard triaxial, FEP insulated
Outside Diameter	3.7 mm maximum
Connector Diameter	7.24 mm maximum
Connector Material	Gold-plated brass or gold-plated beryllium copper
Core Resistance (R_CORE)	1.54 ohms +/- 0.23 ohms (center conductor to center conductor)
Jacket Resistance (R_JACKET)	0.46 ohms +/- 0.09 ohms (outer conductor to outer conductor)
Nominal Capacitance	69.9 pF/m typical
Recommended Torque	Finger tight
Operating Temperature	-51 degC to +177 degC
Weight	0.24 kg
Dimensions	7000 mm x 7.24 mm x 7.24 mm (H x W x D)

Connections and Interfaces

Interface End	Connector Type	Connection Target
End 1	Miniature Male Coaxial Connector	3300 XL Proximitor Sensor
End 2	Miniature Female Coaxial Connector	3300 XL 8 mm Proximity Probe

Installation Guidelines

Ensure the sum of probe length and extension cable length matches the total system length calibrated for the Proximitor Sensor (e.g., a 2.0-meter probe plus this 7.0-meter extension cable equals a 9.0-meter system).
Do not exceed the recommended finger-tight torque when joining gold-plated 3300 XL ClickLoc connectors.
Maintain minimum bend radius during installation to prevent damage to the coaxial core and FEP insulation.
Use conduit or trays to protect the unarmored cable from mechanical cuts, abrasions, or hot surfaces.

Compliance and Certifications

CSA Class I, Division 1 / 2
ATEX Zone 0 / Zone 2
IECEx
RoHS compliant

Model Number / Title	Condition	Availability	Action
Bently Nevada 330901-00-78-10-02-00 3300 XL NSv Yakınlık Prob	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-11-01 3300 XL 8 mm Yakınlık Prob	Original New	In Stock	View Details
Bently Nevada 330104-00-04-10-02-01 3300 XL 8 mm Yakınlık Prob	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Standard Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What does the 070 option represent in the 330130-070-00-05 part number?

The 070 option indicates that the extension cable is exactly 7.0 meters (22.9 feet) in length.

Is the 330130-070-00-05 extension cable armored?

No, the 00 option specifies a standard, unarmored FEP insulated triaxial cable without stainless steel protective armor.

Which hazardous area certifications are covered by the 05 approval option?

The 05 approval option designates CSA, ATEX, and IECEx hazardous area approvals for safe installation in regulated zones.

Which proximity probes are compatible with this 7.0-meter extension cable?

It pairs with Bently Nevada 3300 XL 8 mm proximity probes and standard Proximitor sensors to complete a calibrated 9.0-meter transducer system (typically when using a 2.0-meter probe).
