Omron 3G3JZ-A2022 SYSDRIVE 3G3JZ Series 3-Phase Variable Frequency Drive

Description

Designed for efficient motor speed control and space-saving control cabinet installations, the Omron 3G3JZ-A2022 delivers variable frequency regulation for three-phase AC induction motors up to 2.2kW. Operating on a three-phase AC 200V voltage class, this compact SYSDRIVE 3G3JZ Series inverter features an integrated IP20-rated chassis designed for direct panel or closed wall-mounting configurations, offering high reliability in demanding industrial environments.

Features

• Optimized for maximum applicable motor capacities up to 2.2kW.
• Panel-mounting design with a minimum IP20 enclosure rating for secure cabinet housing.
• High-torque compensation and precise speed control across the operating spectrum.
• Three-phase AC 200V level power architecture ideal for standard industrial motor systems.
• Compact footprint allowing high-density side-by-side DIN rail or backplate configuration.

Applications

• Conveyor drive controls and material handling systems.
• Industrial pump, fan, and ventilation speed regulation.
• Packaging, labeling, and automated bottling machinery.
• Machine tool auxiliary axis control.

Technical Specifications Table

Alternative Models & Compatibility

For modernized systems, the legacy SYSDRIVE series can often be migrated to newer Omron MX2 (3G3MX2) or RX2 series drives. Ensure to verify mounting hole patterns and control terminal differences when substituting older installations with active Omron lines.

Application Pitfalls & Engineering Notes

This unit relies on heat sink convection. To prevent thermal faults (such as Overheat "OH" trip conditions), maintain a minimum mounting clearance of 100mm on the top/bottom and 50mm on the sides when designing layout inside sealed IP20 electrical enclosures.

Commissioning & Wiring Tips

Always install a dedicated noise filter on the line side input to mitigate high-frequency interference. Ensure that control signals (such as 0-10V or 4-20mA speed references) are run using shielded twisted-pair cables with the shield grounded only at the drive end.

Installation Guidelines
