Omron H7CX-A4SD-N | Omron | H7CX-A Series Multifunction Counter/Tachometer

Stokta sadece 7 adet kaldı

Üretici: Omron
Ürün No.: H7CX-A4SD-N
Menşei ülke:Japonya
Ürün Türü: Multifunction Counter/Tachometer
Ödeme: T/T, Western Union
Ağırlık: 2000g
Boyutlar: 4.8 cm x 6.5 cm x 4.8 cm
Gönderim limanı: Xiamen
Garanti: 12 ay

Description

The H7CX-A4SD-N is a compact multifunction counter/tachometer from the H7CX-A series, engineered for precise process monitoring and control in industrial automation. This 4-digit device offers high-visibility display capabilities and is configured for 1-stage setting operations. It is equipped with a transistor output for rapid switching and operates on a supply voltage of 12 to 24 VDC. Designed for reliability and ease of use, the unit features screw terminals for secure external connections, making it a versatile solution for counting applications or rotational speed monitoring in production machinery.

Features

Multifunction capability: Switchable between counter and tachometer modes
Display: High-visibility 4-digit digital readout
Output: Transistor output for high-speed signal switching
Connections: Standard screw terminals for robust physical integration
Versatile Input: 12 to 24 VDC supply voltage range

Applications

Production line part counting
Conveyor belt speed monitoring
Industrial batch control
Machinery cycle rate measurement

Technical Specifications

Parameter	Specification
Manufacturer	Omron
Model	H7CX-A4SD-N
Product Type	Multifunction Counter/Tachometer
Digits	4
Setting Type	1-stage
Output Type	Transistor
Supply Voltage	12 to 24 VDC
Connection Type	Screw terminals
Dimensions	4.8 cm x 6.5 cm x 4.8 cm
Shipping Weight	2 kg

Installation Guidelines

Mounting: Designed for panel mounting. Ensure the panel cutout dimensions are strictly followed to maintain a secure fit.
Wiring: Connect input sensors and output loads according to the specific wiring diagram found in the product manual. Use shielded cables for high-noise environments to prevent false counts.
Terminal Tightening: Use an appropriate screwdriver to ensure all wires are securely fastened to the screw terminals.
Configuration: Utilize the front-panel interface to select the desired operating mode (counter or tachometer) and program the setpoints before putting the system into full operation.

Key Features:

#Counters and Tachometers #Omron H7CX-A

Can the H7CX-A4SD-N function as both a counter and a tachometer?

Yes, this is a multifunction device that can be configured to operate as either a counter or a tachometer depending on the application requirements.

What type of output does this model provide?

The H7CX-A4SD-N features a transistor output, suitable for fast and reliable electronic switching.

What is the supply voltage range for this unit?

The unit operates on a DC supply voltage ranging from 12 to 24 VDC.
