Siemens 6AV6647-0AD11-3AX1 SIMATIC HMI KTP600 Basic Panel

Stokta sadece 2 adet kaldı

Üretici: Siemens
Ürün No.: 6AV6647-0AD11-3AX1
Menşei ülke:Almanya
Ürün Türü: HMI Basic Panels
Barkod: 85371091
Ödeme: T/T, Western Union
Ağırlık: 1360g
Boyutlar: 25.70 x 19.50 x 8.90 cm
Gönderim limanı: Xiamen
Garanti: 12 ay

Description

The Siemens 6AV6647-0AD11-3AX1 is a SIMATIC HMI KTP600 Basic Color PN panel designed for visualization and control tasks in industrial environments. This unit features a 6-inch TFT display with 256 colors and supports both key and touch operation for flexible user interaction. It is equipped with an integrated PROFINET interface for network communication. Configuration is performed using WinCC Flexible 2008 SP2 Compact, WinCC Basic V10.5, or STEP 7 Basic V10.5 and later versions. This product contains open-source software, which is provided free of charge on the enclosed CD.

Features

6-inch TFT color display
256 color depth for clear visualization
Dual input method: keypad and touchscreen operation
Integrated PROFINET interface for industrial Ethernet communication
Configurable with TIA Portal (WinCC Basic) and legacy software (WinCC Flexible)

Applications

Machine-level operator control and monitoring
Simple process visualization
Parameter entry and recipe management
Alarm and message display
Small-scale automation projects

Technical Specifications

Specification	Value
Manufacturer	Siemens
SKU	6AV6647-0AD11-3AX1
Product Series	SIMATIC HMI
Product Type	Basic Panel
Display	6-inch TFT, 256 Colors
Operation	Key and Touch Operation
Interface	PROFINET
Configuration Software	WinCC Flexible 2008 SP2 Compact, WinCC Basic V10.5, STEP 7 Basic V10.5 or higher
Product Lifecycle Status	Phase-Out
Shipping Weight	1.36 kg
Package Dimensions (Calculated)	25.70 x 19.50 x 8.90 cm
Commodity Code	85371091
Export Control (ECCN)	EAR99
Country of Origin	Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: Electrical Hazard. Disconnect and lock out all power sources before installation or servicing. Installation must be performed by qualified personnel familiar with applicable codes and standards. Failure to comply can result in severe injury or death.

1 Prepare the mounting cutout in the control cabinet panel according to the device's mechanical specifications. Ensure the mounting surface is clean, flat, and free of burrs.
2 Insert the HMI panel into the cutout from the front. Secure it from the rear using the provided mounting clamps, tightening them evenly to ensure a proper seal against the panel gasket. Do not overtighten.
3 Connect the functional earth (FE) terminal on the HMI to the control cabinet's ground bar using a short, low-impedance conductor to minimize noise interference.
4 Connect the 24V DC power supply to the designated terminals, observing correct polarity. Use shielded cables for power and communication lines where possible, grounding the shield at one end.
5 Connect the PROFINET cable to the RJ45 port. Ensure proper cable routing away from high-voltage lines to prevent electromagnetic interference. Once all connections are secure, power may be restored to the system.

Key Features:

What is the display size and type for this HMI?

The 6AV6647-0AD11-3AX1 features a 6-inch TFT display with a 256-color depth.

What communication interface does this panel use?

This SIMATIC HMI panel is equipped with an integrated PROFINET interface for industrial Ethernet communication.

What software is required for configuration?

The panel can be configured using Siemens software platforms, specifically WinCC Flexible 2008 SP2 Compact, WinCC Basic V10.5, or STEP 7 Basic V10.5 and later versions.

What are the methods for operator input?

This model supports dual input methods, allowing for both keypad (key) and touchscreen (touch) operation.

What is the product lifecycle status of this HMI?

According to the manufacturer, the 6AV6647-0AD11-3AX1 is in the 'Phase-Out' stage of its product lifecycle.
