Siemens 6AV7813-0BB11-1AC0 SIMATIC Panel PC 877 15" Key Panel PC

Only 8 item(s) left in stock

Manufacturer: Siemens
Product No.: 6AV7813-0BB11-1AC0
Country of origin:Almanya
Product Type: Panel PC
Barcode: 85371091
Payment: T/T, Western Union
Weight: 19g
Dimensions: 40.00 x 60.00 x 40.00 cm
Shipping port: Xiamen
Warranty: 12 months

Description

This is a Siemens 6AV7813-0BB11-1AC0 SIMATIC Panel PC 877, an industrial computer designed for machine-level control and visualization tasks. It features a 15-inch keypad display with a 1024x768 resolution, powered by an Intel Pentium 4 2.8 GHz processor. The system is configured with 512MB of DDR266 SDRAM, an 80 GB EIDE hard disk drive, and a DVD-ROM drive. It operates on a 110-230V AC power supply and comes pre-installed with Windows XP Professional with a multi-language user interface.

Features

15-inch display with integrated keypad for operator input.
1024 x 768 pixel screen resolution for clear process visualization.
Intel Pentium 4 processor operating at 2.8 GHz with a 533 MHz FSB.
Equipped with 512 MB of DDR266 SDRAM.
Includes an 80 GB EIDE 3.5" hard disk drive and a DVD-ROM drive.
Pre-loaded with Windows XP Professional (Multi-Language User Interface).

Applications

Human-Machine Interface (HMI) for manufacturing lines.
Process control and data acquisition systems.
Industrial automation and SCADA client nodes.
Machine-level data logging and diagnostics.

Technical Specifications

Specification	Value
Manufacturer	Siemens
Product Series	SIMATIC Panel PC 877
Display	15" Keypad Interface
Resolution	1024 x 768 pixels
Processor	Intel Pentium 4, 2.8 GHz
Front Side Bus (FSB)	533 MHz
Cache	512KB SLC
Memory (RAM)	512 MB DDR266 SDRAM (1x512MB)
Storage	80 GByte EIDE 3.5" Hard Disk Drive
Optical Drive	DVD-ROM
Operating System	Windows XP Professional MUI (EN, GE, FR, IT, SP, JP, CHN, KOR)
Power Supply	110-230V AC
Power Cable	Europe standard
Product Lifecycle Phase	Obsolete
Shipping Weight	19.00 kg
Package Dimensions	40.00 x 60.00 x 40.00 cm
Commodity Code	85371091
ECCN	5D002
Country of Origin	Germany (Estimate)

Installation Guidelines

CRITICAL WARNING: Hazardous voltages are present. Installation must be performed by qualified personnel only. Ensure the control cabinet is de-energized and locked out before beginning work. Failure to comply can result in severe injury or death.

1 Verify the control cabinet is de-energized and locked out according to safety procedures.
2 Prepare the panel cutout according to the device's mechanical specifications. Ensure the mounting surface is clean and flat.
3 Insert the Panel PC into the cutout from the front and secure it evenly using the provided mounting clamps. Do not overtighten.
4 Connect a low-impedance protective earth (PE) conductor to the designated grounding terminal on the PC chassis.
5 Connect the 110-230V AC power supply cable to the unit's power input connector. Ensure the cable is properly secured.
6 Connect all required communication, peripheral, and I/O cables. Route cables to prevent strain and interference.
7 After verifying all connections are secure, close the cabinet door, remove the lockout/tagout device, and re-energize the system.

Key Features:

#Panel PC #SIMATIC Panel PC

What operating system is installed on the 6AV7813-0BB11-1AC0?

This Panel PC comes pre-installed with Windows XP Professional, featuring a Multi-Language User Interface (MUI) that includes English, German, French, Italian, Spanish, Japanese, Chinese, and Korean.

What is the screen size and resolution?

The unit features a 15-inch display with an integrated keypad for operator input. The screen resolution is 1024 x 768 pixels.

What are the main processing and memory specifications?

It is equipped with an Intel Pentium 4 2.8 GHz processor, 512 MB of DDR266 SDRAM, and an 80 GB EIDE hard drive for storage.

What is the required input voltage for this Panel PC?

The integrated power supply is rated for a wide input range of 110-230V AC. This specific model is supplied with a power cable for European standard outlets.
