Allen-Bradley 22B-A8P0N104 PowerFlex 40 Wechselstromantrieb

Description

The Allen-Bradley 22B-A8P0N104 is an adjustable frequency AC variable speed drive operating within the PowerFlex 40 product line designed for precise sensorless vector motor speed control across automated industrial processes. Delivering 1.5 kW (2 HP) of power output, this digital control unit regulates speed and torque commands to support industrial machinery demanding consistent operational performance. The device houses a sophisticated microprocessor-based inverter logic section that remains entirely isolated from incoming and outgoing power circuits to minimize electrical noise interference and protect downstream processing elements. Equipped with a built-in Device Peripheral Interface (DSI) communication layout, the hardware enables integrated system networking and auxiliary peripheral device configurations. Its versatile multi-phase input power handling provides seamless integration into varying factory floor infrastructures while driving crucial automated sub-assemblies.

Features

• Utilizes microprocessor-based inverter logic completely isolated from internal power circuitry.
• Integrated software algorithm on high-voltage variants to limit reflected waveform risks on extended cable lengths.
• Advanced hardware protection including MOV shielding spanning phase-to-phase and phase-to-ground configurations.
• Built-in Device Peripheral Interface (DSI) supporting stable serial link connection mapping.
• Reliable gold-plated plug-in connector configurations across printed circuit boards.
• Capable of dense zero-stacked installation with side-by-side drive clearance within designated environments.

Applications

• Variable speed motor control applications in automated conveyors and material handling systems.
• Industrial fan and pump velocity regulation loops requiring precise flow adjustments.
• Integrated machinery speed tuning processes utilizing multi-drive networked configurations.

Technical Specifications

Performance Specifications

Environmental Specifications

General Specifications

Installation Guidelines

• Mount multiple units side-by-side using a zero-stacked configuration with no clearance spacing when working in maximum ambient environments of 40 degC.
• Ensure a minimum of one inch of physical spacing between adjacent drives when operating in ambient temperatures spanning 41 degC to 50 degC.
• Leverage the internal MOV phase-to-ground protection, utilizing the provided hardware jumpers to isolate or remove the ground reference connection when requested by specific plant grounding rules.
• Maintain standard environmental boundaries by placing the device under an altitude limit of 1000 Meters to protect thermal performance indices.

Compliance and Certifications

• NFPA 70 - US National Electrical Code
• NEMA ICS 3.1 - Safety standards for Construction and Guide for Selection, Installation and Operation of Adjustable Speed Drive Systems
• NEMA 250 - Enclosures for Electrical Equipment
• UL 508C - Underwriter's Laboratory
• CAN/CSA-C22 No. 14-M91 - Canadian Standards Association
• C-UL Marking
• UL Listing
• IEC 146 International Electrical Code
• NSF - National Sanitation Foundation
• CE Marked (Low Voltage Directive 73/23/EEC, EN50178)
• CE Marked (EMC Directive 89/336/EEC, EN61800-3)
• C-Tick EMC Standards for Australia / New Zealand
• ISO-9001 Quality Standards & ISO-14001 Environmental Standards Certified Manufacturing Locations
