Beckhoff C6525-0050 C65xx Fanless Built-In Industrial PC

Beckhoff C6525-0050 C65xx Fanless Built-In Industrial PC

Nur noch 10 Artikel auf Lager verfügbar

  • Hersteller: BECKHOFF

  • Produkt-Nr.: C6525-0050

  • Herkunftsland:Deutschland

  • Produkttyp: Industrial PCs

  • Zahlung: T/T, Western Union

  • Gewicht: 5900g

  • Abmessungen: 330 mm x 275 mm x 82 mm

  • Versandhafen: Xiamen

  • Garantie: 12 Monate

Vollständige Details anzeigen
Produktbeschreibung
FAQ
Versand Rückgaben
Zusätzliche Details
Bewertungen

Description

Designed for space-saving mounting within control cabinets, the Beckhoff C6525-0050 cabinet-mounted fanless Industrial PC delivers high-performance computing in demanding industrial environments. This compact IPC features an innovative external cooling concept, projecting its passive heat sink through the rear wall of the enclosure to dissipate heat outside the control housing. This thermal management design maintains an IP65 protection rating on the external heat sink while keeping the internal components rated at IP20. Standard configurations integrate 4th Generation Intel processors, highly reliable storage interfaces, and versatile connectivity options for demanding automation, HMI, and machine control tasks.

Features

  • Passive heat dissipation through an external heat sink structure, eliminating moving fans and increasing system MTBF.
  • Equipped with a 3.5-inch motherboard supporting high-efficiency 4th Generation Intel processors.
  • Integrated SATA RAID 1 controller utilizing Intel Rapid Storage Technology for optimized data redundancy.
  • Dual on-board 100/1000BASE-T Gigabit Ethernet interfaces for high-speed network communication.
  • Easily accessible storage slots and system clock battery located at the rear of the housing.
  • Robust steel housing designed specifically for mounting in control cabinet panels.

Applications

  • Machine tool automation and visualization interfaces.
  • Central control nodes in automotive manufacturing lines.
  • Distributed process control systems requiring fanless operation.
  • Data logging and gateway applications in power generation and distribution.

Technical Specifications

Manufacturer Beckhoff Automation
Model/Part Number C6525-0050
Processor Intel Celeron 2000E 2.2 GHz, 2 Cores (TC3: 50)
Motherboard 3.5-inch form factor for 4th Gen Intel Celeron/Core i3/i5/i7
System Memory 2 GB DDR3L RAM (expandable to 16 GB)
Graphics Integrated Intel HD Graphics with 1 x DVI connector
Storage Interfaces 1 x slot for 2.5-inch HDD or SSD, 1 x slot for CFast
Network Dual onboard Ethernet ports (2 x 100/1000BASE-T RJ45)
I/O Interfaces 1 x RS232 serial port, 2 x USB 3.0 ports, 2 x USB 2.0 ports
Expansion Slots 1 x Mini PCI slot (free for factory-installed cards)
Power Input 24 V DC
Ingress Protection External heat sink side: IP65, Internal cabinet side: IP20
Operating Temperature External: 0 to 45 degC, Internal: 0 to 55 degC
Dimensions (W x H x D) 330 mm x 275 mm x 82 mm
Weight 5.9 kg (basic configuration)

Connections and Interfaces

Port Type Function Description
RJ45 (x2) Gigabit Ethernet connection (100/1000BASE-T) for automation and factory networks
DVI-D (x1) Digital video output for local machine monitors and control panels
USB 3.0 (x2) High-speed peripheral connections for external storage or diagnostic devices
USB 2.0 (x2) Standard peripheral connections for keyboard, mouse, or legacy devices
D-sub 9-pin (x1) RS232 serial interface for legacy controllers or process instrumentation
DC Terminal 24 V DC main system power input connection

Installation Guidelines

  • Convection Space: Ensure a minimum of 20 cm of clear, unobstructed space around the external passive heat sink to allow proper natural air convection.
  • Panel Mounting: Verify that the cabinet cutout matches the specified dimensions and that the sealing gasket is evenly compressed to maintain the IP65 external seal.
  • Grounding: Connect the IPC chassis to the cabinet's central functional ground rail using a low-impedance grounding strap to prevent electromagnetic interference.
  • Hot-swapping: Always disconnect the primary 24 V DC power supply before performing hardware maintenance or exchanging the system clock battery.

Compliance and Certifications

  • CE Compliant
Loading product navigation…
Key Features:
#Beckhoff C65 Series #Industrial PCs

How does the cooling system function on the Beckhoff C6525-0050?
The C6525-0050 uses a passive, fanless external cooling concept. The unit is mounted so its heat sink structures project outside the rear panel of the control cabinet, allowing heat to dissipate into the external environment via natural convection.

What are the protection ratings for the internal and external sections of this IPC?
The external heat sink assembly protruding from the cabinet is rated at IP65, protecting it against dust and low-pressure water jets. The internal chassis housed inside the cabinet is rated at IP20.

Does the C6525-0050 support RAID configurations?
Yes, it contains an on-board SATA RAID 1 controller utilizing Intel Rapid Storage Technology to provide mirroring and data redundancy when using compatible storage configurations.

What is the recommended clearance around the external heat sink?
A minimum of 20 cm of free space is required around the external heat sink to ensure sufficient passive air circulation and prevent thermal throttling.
