Bently Nevada 330180-X1-05MOD:145193-01 3300 XL Proximitor Sensor

Description

330180-X1-05MOD:145193-01: This 3300 XL Proximitor Sensor is configured with Option X1 for DIN-rail mounting, Option 05 for multiple hazardous area agency approvals, and is custom-calibrated under modification 145193-01 for non-standard target materials.

In contrast to standard 330180 variants calibrated for AISI 4140 steel, this Proximitor sensor includes factory recalibration circuitry to maintain precise eddy-current measurement linearity on specific non-standard alloys. It integrates oscillator and detection electronics to condition proximity probe signals into a continuous displacement output, directly compatible with machinery protection monitors such as the Bently Nevada 3500 system.

Features

• DIN-rail mount form factor specified by option X1 for secure electrical enclosure mounting
• Multiple hazardous area approvals under option 05 including ATEX, IECEx, and CSA intrinsic safety standards
• Custom target material calibration under Bently Nevada engineering modification MOD 145193-01
• Converts eddy-current RF signals into a continuous voltage output proportional to target distance
• Seamlessly integrates with 3300 XL 5mm/8mm 9m proximity probes and extension cables

Applications

• Shaft radial vibration and axial position monitoring on high-speed industrial machinery
• Heavy industrial applications in power generation, oil and gas, petrochemical, and chemical processing
• Specialized rotor dynamic analysis on turbomachinery utilizing non-standard shaft materials

Ordering Information

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mount securely on a standard 35 mm DIN rail in an environmentally protected enclosure.
• Ensure proper electrical isolation and shield grounding to prevent interference from external noise.
• Connect coaxial cable from the extension cable to the Proximitor coaxial connector, ensuring it is finger-tight.
• Maintain an appropriate probe-to-target gap matching the linear range of 10 to 90 mils.

Compliance and Certifications

• ATEX/IECEx Intrinsically Safe (Option 05)
• CSA Class I, Division 1, Groups A, B, C, D (Option 05)
• CE Compliant
