Honeywell 51453328-501 UDA Series Additional Analog & Relay Card

Nur noch 6 Artikel auf Lager verfügbar

Hersteller: Honeywell
Produkt-Nr.: 51453328-501
Herkunftsland:Vereinigte Staaten
Produkttyp: Analyzer Expansion Modules
Zahlung: T/T, Western Union
Gewicht: 500g
Versandhafen: Xiamen
Garantie: 12 Monate

Description

Providing extended output capabilities for continuous process monitoring systems, this hardware expansion board, the Honeywell 51453328-501, integrates directly into the host UDA2182 Universal Dual Analyzer chassis. This card increases the control and alarm-handling capabilities of your process analyzer by introducing supplementary auxiliary analog outputs and dedicated physical relay contacts, ensuring seamless signal transmission to distributed control systems (DCS) or auxiliary control loops.

Features

Expands host analyzer capabilities to support additional physical control and alarm loops.
Provides isolated analog output channels for highly reliable process variable retransmission.
Integrated dry relay contacts configurable for high/low alarms, diagnostics, or limit controls.
Ruggedized field terminal blocks designed for secure industrial wire terminations.
Plug-and-play form factor simplifies field upgrades and minimizes system downtime.

Applications

Municipal water treatment facilities using Honeywell UDA2182 multi-parameter analyzers.
Industrial boiler feed-water monitoring systems demanding auxiliary signal retransmission.
Chemical processing plants requiring automated hardwired shutdown actions via relay interlocks.
Wastewater neutralization and effluent monitoring systems.

Technical Specifications

Manufacturer	Honeywell
Part Number	51453328-501
Series Compatibility	UDA2182 Universal Dual Analyzer
Module Type	Additional Analog Output and Relay Card
I/O Functionality	Auxiliary Analog Output & Relay Contact Outputs
Installation Slot	Internal Dedicated Option Slot
Shipping Weight (Calculated)	1.0 kg

Alternative Models & Compatibility

The 51453328-501 card is specifically engineered for the UDA2182 analyzer series. When replacing older module revisions or retrofitting legacy analytical instrumentation, confirm that the host analyzer's firmware supports the additional analog and relay configuration options in the setup menu. Ensure the host unit's power supply capacity aligns with the overall system card loading before installation.

Application Pitfalls & Engineering Notes

To prevent cross-talk and measurement instability, signal loop cables must be isolated from high-voltage AC lines. Do not run low-voltage analog signal wires inside the same conduit as high-current relay switched lines. Inductive load switching with the on-board relays requires external snubber protection to avoid transient voltage feedback to the card circuitry.

Installation Guidelines

CRITICAL WARNING

Disconnect all electrical power to the host analyzer and verify the absence of voltage before opening the enclosure door. Failure to isolate the power supplies can cause severe shock, card damage, or system-wide communication faults.

1 Power down the UDA2182 host analyzer and secure with lock-out/tag-out procedures.

2 Open the main housing and locate the designated option slot on the internal chassis.

3 Carefully align the edge connector of the 51453328-501 card with the motherboard socket and press firmly until fully seated.

4 Secure the card with mounting screws to prevent vibration-induced dislodgement.

5 Terminate the analog signal and relay loop cables onto the plug-in terminal blocks, ensuring correct polarity.

Key Features:

#Analyzer Expansion Modules #Honeywell UDA Series

What is the primary function of the Honeywell 51453328-501 card?

It is an option board designed to expand the input/output capacity of a UDA2182 Universal Dual Analyzer, providing additional physical relays and analog outputs.

Does the UDA2182 require firmware upgrades after installing this card?

The card is designed to be auto-detected by standard UDA2182 firmware, but it is recommended to verify firmware compatibility and menu options if upgrading older analyzers.

Can I hot-swap this card while the analyzer is running?

No. Power down the host instrument completely before inserting or removing the 51453328-501 card to avoid physical damage to the module or host motherboard.
