Mitsubishi Electric GT2708-STBD GOT2000 Series Graphic Operation Terminal

Description

Designed for advanced machine visualization and control, the GT2708-STBD serves as a high-performance human-machine interface (HMI) within the Mitsubishi Electric GOT2000 Series. Featuring an 8.4-inch SVGA TFT color display, this advanced model supports intuitive multi-touch gesture operations such as pinching, zooming, and swiping to streamline operator interaction and improve complex process monitoring.

Engineered for industrial reliability, this operator terminal features a robust fanless design housed in a compact black frame. The terminal integrates seamlessly with Mitsubishi Electric programmable logic controllers (PLCs) as well as third-party automation systems, providing high-speed processing and robust communication capability directly from the plant floor.

Features

• Multi-Touch Gestures: Supports intuitive gesture operations including screen zoom, scroll, and multi-point touch controls.
• High-Resolution Display: Equipped with an 8.4-inch TFT color screen with SVGA (800 x 600) resolution for sharp, legible graphics.
• Flexible Installation: Suitable for both horizontal and vertical mounting orientations within control cabinets.
• Low Maintenance: Uses a self-cooling, fanless thermal management design to eliminate dust intake issues.
• High Environmental Tolerance: Designed to operate reliably in harsh ambient temperatures up to 55 degC.

Applications

• Automotive assembly and robotic cells
• Packaging machinery and material handling systems
• Water and wastewater treatment facilities
• Food and beverage production lines
• Chemical and pharmaceutical processing plants

Technical Specifications

Connections and Interfaces

Installation Guidelines

• Mounting Location: Install inside a sealed IP-rated control panel to protect against oil mist, corrosive or flammable gases, and conductive dust.
• Panel Angle: Ensure the mounting surface is flat. For vertical installations, note the reduced ambient temperature ceiling of 50 degC.
• Wiring Safety: Ensure all power is disconnected before connecting the 24VDC supply lines to the M3 clamp terminals. Tighten terminal screws to the recommended 0.5 to 0.8 N.m torque.
• Grounding: Connect the ground terminal using a dedicated ground wire of 2 mm² or greater for optimal noise resistance.

Compliance and Certifications

• JIS B 3502: Compliant for vibration and shock resistance standards.
• IEC 61131-2: Compliant with international programmable controller standards.
