Omron NS10-TV00-V2 NS Series Programmable Terminal

Description

Designed for industrial automation control panels, the NS10-TV00-V2 serves as a high-performance operator interface within the Omron NS Series lineup. This unit features a high-visibility 10.4-inch TFT display equipped with an LED backlight, rendering a sharp 640 x 480 dot resolution for machine status monitoring and diagnostic visualization. Running on a standard 24 VDC system, the unit is housed in a robust, ivory-colored protective casing optimized for panel mounting in manufacturing environments. This non-Ethernet variant is engineered for straightforward serial integration into dedicated machine control architectures.

Features

• 10.4-inch TFT active-matrix display with long-life LED backlighting.
• High-density 640 x 480 pixel resolution for clear graphical interfaces.
• Durable ivory-colored housing designed for front-panel integration.
• Passive heat dissipation engineering with low energy demand (25 W maximum power consumption).
• Optimized for deployment in non-corrosive gas environments.

Applications

• Automated assembly lines and automotive manufacturing.
• Packaging, wrapping, and material handling systems.
• Water and wastewater municipal treatment monitoring.
• General industrial HVAC and environmental system interfaces.

Technical Specifications

Installation Guidelines

• Ensure the installation cutout matches the exact panel dimensions required for the NS10 series terminal to maintain ingress protection seals.
• Connect the unit to a stable 24 VDC power supply, ensuring polarity is correct before applying power.
• Maintain adequate clearances behind the terminal housing to facilitate natural convection cooling.
• Do not install the terminal in areas subject to direct sunlight, extreme temperature fluctuations, or corrosive chemical fumes.
