Schneider 990NAD21810 Modbus Plus Drop-Kabel

The 990NAD21810 is a specialized Modbus Plus Drop Cable manufactured by Schneider Electric, designed to facilitate robust network communication between a junction box and a device with a Sub-D9 connector. This cable features a length of 2.4 meters (8 feet) and is configured for left-side connection, ensuring organized cable routing in industrial control cabinets and network infrastructures.

Features

• Modbus Plus network compatibility

• Cable length: 2.4 meters (8 feet)

• Connector configuration: Junction box to Sub-D9

• Left-side connector orientation

• High-durability design for industrial network environments

Applications

• Modbus Plus fieldbus network installations

• PLC and I/O communication wiring

• Industrial automation infrastructure upgrades

• Connectivity between network junction boxes and communication ports

Technical Specifications

Installation Guidelines

• Cable Routing: Ensure the cable is routed away from high-voltage power lines to minimize potential electromagnetic interference (EMI) on the network signal.

• Bending Radius: Observe the minimum bending radius during installation to prevent internal conductor fatigue or damage to the shielding.

• Connector Security: Ensure the Sub-D9 connector is fully seated and the locking screws are tightened to prevent accidental disconnection due to vibration.

• Network Topology: Verify that the drop cable complies with the total segment length limitations defined by the Modbus Plus network specifications to maintain signal integrity.
