Schneider Altivar 11 ATV11HU09M2A Frequenzumrichter

Description

The ATV11HU09M2A is a Variable Speed Drive belonging to the Altivar 11 series, developed by Schneider Electric for the efficient control of small asynchronous motors. Rated for a power output of 0.37 kW, this drive is designed to operate with a 230 V single-phase power supply. It features an IP20-rated enclosure, providing a compact solution for mounting in electrical cabinets or control panels where space is at a premium.

This drive provides essential speed regulation for various low-power industrial and commercial machinery. While it is now classified as an obsolete product, it remains a reliable choice for maintaining or extending the service life of existing systems that utilize the Altivar 11 control platform.

Features

• Optimized for 0.37 kW asynchronous motor applications
• 230 V single-phase supply input
• Compact and lightweight design for space-constrained installations
• IP20 degree of protection
• Designed for standard speed control and motor management tasks

Applications

• Small industrial machinery and conveyors
• Commercial ventilation fans
• Compact pump systems
• Specialized process control equipment

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a vertical position on a non-flammable surface to ensure proper heat dissipation.
• Environment: Avoid mounting in areas exposed to dust, moisture, corrosive gases, or extreme temperature fluctuations.
• Ventilation: Ensure adequate air circulation around the unit; keep the ventilation slots clear of any obstructions.
• Grounding: Always connect the drive to a reliable protective earth (PE) terminal to maintain electrical safety.
• Cable Routing: Separate power supply cabling from sensitive control signal wiring to prevent electromagnetic interference.
