Schneider Electric ATV212WD22N4 Altivar 212 Frequenzumrichter

Description

The ATV212WD22N4 is an Altivar 212 series variable frequency drive (VFD) engineered for high-performance motor control in industrial applications. Featuring a power rating of 22 kW and designed for 3-phase 480 V electrical systems, this controller provides precise speed regulation and energy optimization for motor-driven equipment. The unit is housed in an IP55-rated enclosure for robust protection against dust and water ingress and complies with EMC class C2 standards for reduced electromagnetic interference. The ATV212WD22N4 is an ideal solution for industrial environments requiring reliable, scalable process control and operational efficiency.

Features

• Rated for 22 kW power output in 3-phase 480 V configurations
• IP55-rated enclosure for reliable operation in demanding environments
• Integrated EMC class C2 filtering for enhanced electromagnetic compatibility
• Designed for seamless integration into industrial automation networks
• Robust construction supporting energy-efficient motor management

Applications

• HVAC systems (Fans and Pumps)
• Industrial water and wastewater processing
• Conveyor systems and material handling
• Building automation applications
• General purpose industrial motor control

Technical Specifications

Installation Guidelines

• Mounting: Install the unit in a vertical orientation to ensure optimal cooling and airflow through the integrated thermal management system.
• Clearance: Maintain the manufacturer-recommended clearances around the drive to prevent overheating during continuous operation.
• Grounding: Establish a high-integrity connection to the system ground bus to ensure compliance with EMC class C2 requirements and operational safety.
• Cable Routing: Use shielded motor cables to minimize EMI and separate power and signal cable paths to prevent communication interference.
• Environmental: While IP55 rated, install the drive in a location shielded from extreme direct weather exposure and heavy chemical corrosive vapours.
