Schneider Electric ATV61HD45N4S337 Altivar 61 Frequenzumrichter

Description

The Schneider Electric ATV61HD45N4S337 is a variable frequency drive (VFD) from the Altivar 61 range, engineered for high-performance motor control in industrial environments. Rated for 45 kW (60 HP), this unit supports a 380 to 480 V three-phase input supply. Featuring a reinforced design and an IP20 protection rating, it is built to provide reliable torque and speed management for demanding HVAC, pumping, and general machinery applications.

Features

• Optimized motor speed and torque control
• 45 kW (60 HP) power output rating
• Input voltage range: 380 to 480 V
• Reinforced design for industrial environments
• IP20 ingress protection rating

Applications

• Variable torque applications (fans and pumps)
• Industrial process machinery
• HVAC system motor control
• Material handling and conveyor systems

Technical Specifications

Installation Guidelines

• Mounting: Install the drive in a vertical position to ensure effective airflow through the integrated cooling system.
• Ventilation: Maintain minimum clearance distances around the unit as specified in the installation manual to prevent thermal overload.
• Grounding: Connect the drive chassis to a solid earth ground to ensure operational safety and minimize electromagnetic interference.
• Wiring: Use shielded cabling for motor connections to comply with EMC requirements.
• Environment: Mount within an enclosure suitable for an IP20-rated device, ensuring protection from dust, moisture, and extreme temperatures.
