منبع تغذیه سوئیچ آلن-برادلی MIM105-Q6949 80026-096-01

The Allen-Bradley MIM105-Q6949 (also referenced as 80026-096-01) is a Switch Power Supply designed for reliable voltage conversion in industrial automation environments. This unit is engineered to accept a 48V DC input and provide a stable 24V DC output, making it suitable for powering sensitive control components and instrumentation.

The MIM105-Q6949 supports an input current of 1.5A maximum and delivers an output current of 2A. Its design focuses on efficient power regulation and consistent performance, ensuring that connected devices receive the necessary voltage levels for stable operation within industrial control architectures.

Features

• Designed for efficient DC to DC voltage conversion.
• Supports an input voltage of 48V DC with a maximum current rating of 1.5A.
• Provides a regulated output of 24V DC at 2A.
• Compact design for integration into various control panels and equipment.

Applications

• Industrial automation and control systems.
• Instrumentation and sensor power distribution.
• Voltage regulation for 24V DC control circuits.

Technical Specifications

Installation Guidelines

• Ensure that the input power source matches the specified 48V DC rating.
• Verify that the load connected to the output does not exceed the 2A rating to maintain stable operation.
• Mount the power supply in an enclosure with adequate ventilation to prevent overheating.
• Ensure all wiring connections are secure to prevent voltage drops or intermittent operation.
• Follow standard industrial practices for grounding and cabling to minimize electrical noise.
