Bently Nevada 330104-00-06-10-02-05 3300 XL 8 mm Proximity Probe

Description

An unthreaded length of 0 mm (Option 00) on an M10 x 1 threaded case of 60 mm (Option 06) defines the 330104-00-06-10-02-05, which is a 3300 XL 8 mm metric proximity probe equipped with protective stainless steel armor. This probe operates on eddy-current technology to track shaft vibration, radial displacement, and thrust position in machinery protection and condition monitoring systems.

This specific metric configuration includes a 1.0-meter total length (Option 10) and a miniature ClickLoc coaxial connector on standard cable (Option 02). With Option 05, this probe complies with CSA, ATEX, and IECEx hazardous area criteria. The integral stainless steel armor safeguards the internal coaxial cable from abrasion, cutting, and environmental degradation, distinguishing this model from the unarmored 330103 variants.

Features

• Metric thread profile utilizing M10 x 1 threading with protective stainless steel armor.
• Option 00 specifies a 0 mm unthreaded length, providing a fully threaded case.
• Option 06 establishes an overall case length of 60 mm.
• Option 10 provides a total cable length of 1.0 meter (3.3 feet).
• Option 02 configures a miniature ClickLoc coaxial connector with standard coaxial cable.
• Option 05 delivers CSA, ATEX, and IECEx safety certifications.
• PPS (polyphenylene sulfide) tip material provides structural integrity and fluid sealing.

Applications

This proximity probe is used across heavy industries to manage critical asset monitoring, including:

• Steam and gas industrial turbines
• Centrifugal and axial turbocompressors
• High-pressure feed pumps and process fans
• Electric power generators and motors
• Industrial gearboxes and high-speed rotating shafts

Ordering Information

Technical Specifications

Installation Guidelines

• Maintain a minimum clearance of 20 mm around the probe tip to prevent cross-talk or casing interference.
• Ensure the probe mounting torque does not exceed 15 Nm (133 in-lb).
• Protect the ClickLoc coaxial connector from oil and moisture contamination.
• Observe a minimum cable bend radius of 50.8 mm (2.0 in) for the armored section.

Compliance and Certifications

• ATEX/IECEx: Intrinsically Safe (Ex ia IIC T5...T1 Ga) and Non-Sparking (Ex nA/ec IIC T5...T1 Gc)
• North American (CSA): Class I, Zone 0/1/2, Groups A, B, C, D
• RoHS: Compliant with European Community Directive 2011/65/EU
• Functional Safety: SIL 2 certified
