Bently Nevada 330130-060-02-05 3300 XL Standard Extension Cable

فقط 6 قلم کالا در انبار باقی مانده است

تولیدکننده: Bently Nevada
شماره محصول: 330130-060-02-05
کشور سازنده:ایالات متحده آمریکا
نوع محصول: 3300 XL Standard Extension Cable
بارکد: 8537101190
پرداخت: حواله بانکی (T/T)، وسترن یونیون
وزن: 250g
ابعاد: 200 mm x 200 mm x 30 mm (H x W x D)
بندر حمل و نقل: شیامن
گارانتی: ۱۲ ماه

Description

Option 060 (6.0 meters cable length) and Option 02 (standard cable with integrated fluorosilicone connector protector) specify this 3300 XL Standard Extension Cable configuration — 330130-060-02-05. This cable provides the physical and electrical transmission link between a 3300 XL 8 mm proximity probe and a 3300 XL Proximitor sensor in non-contact displacement monitoring chains. In a complete transducer system, the total length of the probe and extension cable must match the required total system length of the Proximitor sensor (typically 5.0 or 9.0 meters). The pre-installed connector protector (Option 02) provides environmental sealing for the gold-plated ClickLoc connector joint, preventing fluid, oil, dust, and moisture ingress in aggressive machinery environments. Option 05 designates the certificate package for explosive or hazardous atmospheres, supporting installation requirements across globally certified process environments.

Features

Option 060 designates a 6.0 meters (19.7 feet) cable length, forming a matched 7.0 or 9.0 meters system when combined with the corresponding probe.
Option 02 includes standard cable pre-equipped with a fluorosilicone connector protector to seal and guard the connector joint against environmental contaminants.
Option 05 provides hazardous area approvals including CSA, ATEX, and IECEx certifications.
Gold-plated brass and beryllium copper ClickLoc connectors provide positive locking with simple finger-tightening.
Fluorinated Ethylene Propylene (FEP) cable insulation and outer jacket provide chemical, oil, and moisture resistance.
Cable electrical resistance measures 1.32 ohms +/- 0.21 ohms for the core conductor and 0.39 ohms +/- 0.08 ohms for the outer jacket conductor over the 6.0 meters length.

Applications

Shaft vibration and axial position measurement on high-speed rotating machinery.
Turbine, generator, compressor, and pump protective monitoring systems.
Environments requiring certified electrical apparatus for explosive or hazardous gas zones.
Machinery installations exposed to lubricating oils, hydraulic fluids, and severe moisture.

Ordering Information

Option Code	Value on This SKU	Description
Orderable Part Number	330130-060-02-05	3300 XL Standard Extension Cable, 6.0 m length, standard cable with connector protector, CSA/ATEX/IECEx approved
A - Cable Length Option	060	6.0 meters (19.7 feet)
B - Connector Protector and Cable Option	02	Standard cable with connector protector
C - Agency Approval Option	05	CSA, ATEX, IECEx approvals

Technical Specifications

Manufacturer	Bently Nevada
Part Number / Model	330130-060-02-05
Product Type	3300 XL Standard Extension Cable
Cable Length	6.0 meters (19.7 feet)
Cable Type	Standard triaxial coaxial cable with FEP insulation
Connector Option	Standard cable with connector protector (Option 02)
Connector Material	Gold-plated brass and gold-plated beryllium copper
Core Conductor Resistance	1.32 ohms +/- 0.21 ohms (typical)
Outer Jacket Resistance	0.39 ohms +/- 0.08 ohms (typical)
Cable Capacitance	69.9 pF/m (21.3 pF/ft) typical
Operating Temperature	-52 degC to +177 degC
Storage Temperature	-52 degC to +177 degC
Agency Approvals	CSA, ATEX, IECEx (Option 05)
Outside Diameter of Cable	3.7 mm maximum
Outside Diameter of Connector Protector	12.4 mm maximum
Weight	0.25 kg
Dimensions	200 mm x 200 mm x 30 mm (H x W x D)

Connections and Interfaces

Connector End	Connector Type	Function
Probe Connection End	Miniature female coaxial ClickLoc	Connects to the miniature male coaxial connector of the proximity probe
Sensor Connection End	Miniature male coaxial ClickLoc	Connects to the female coaxial connector of the Proximitor sensor

Installation Guidelines

Verify that the combined length of the proximity probe and the 6.0 m extension cable equals the calibrated system length specified on the Proximitor sensor label.
Tighten the coaxial ClickLoc connectors finger-tight until they physically click; do not use mechanical tools.
Slide and fully seat the fluorosilicone connector protector sleeve over the mated connector joint to establish a moisture-proof seal.
Observe a minimum bend radius of 25.4 mm (1.0 inch) for the FEP coaxial cable during routing.
Secure the extension cable using non-conductive, oil-resistant cable ties or protective conduit to prevent physical wear and high-voltage interference.

Compliance and Certifications

CSA Certified: Class I, Division 1 and 2, Groups A, B, C, D; Class II, Division 1 and 2; Class III
ATEX/IECEx: Zone 0, Zone 1, and Zone 2 explosive gas atmospheres
RoHS Compliant

Model Number / Title	Condition	Availability	Action
بنتلی نوادا 330901-00-78-10-02-00 پروب نزدیکی NSv 3300 XL	Original New	In Stock	View Details
بنتلی نوادا 330104-00-04-10-11-01 پروب نزدیکی 8 میلی‌متری 3300 XL	Original New	In Stock	View Details
بنتلی نوادا 330104-00-04-10-02-01 پروب نزدیکی 8 میلی‌متری 3300 XL	Original New	In Stock	View Details

Key Features:

#Bently Nevada 3300 XL #Standard Extension Cables

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

What is the configuration of the Bently Nevada 330130-060-02-05 extension cable?

This cable is configured with a length of 6.0 meters, standard cable type equipped with an integrated connector protector (Option 02), and hazardous area agency approvals (Option 05) including CSA, ATEX, and IECEx.

Which proximity probes and sensors is this cable compatible with?

The cable is part of the 3300 XL 8 mm proximity transducer system. It is designed to link a 3300 XL 8 mm probe with a 3300 XL Proximitor sensor. The combined length of the probe and extension cable must match the total system length designated by the sensor.

How does the connector protector on this cable benefit the system?

Option 02 includes a pre-installed fluorosilicone connector protector. This component seals the connection joint between the probe and the extension cable, protecting the sensitive gold-plated ClickLoc contacts from environmental liquids, dust, and moisture.

What is the temperature rating for this standard extension cable?

The 330130-060-02-05 cable is rated for an operating and storage temperature range of -52 degC to +177 degC (-62 degF to +350 degF).
