Beckhoff C6670-0010 Control Cabinet Industrial Server

Only 10 item(s) left in stock

Manufacturer: BECKHOFF
Product No.: C6670-0010
Country of origin:Németország
Product Type: Industrial Servers
Payment: T/T, Western Union
Weight: 17000g
Dimensions: 410 mm x 480 mm x 201 mm
Shipping port: Xiamen
Warranty: 12 months

Description

Centralizing intensive industrial processing and virtualization workloads directly inside the control cabinet, the Beckhoff C6670-0010 is a high-performance, rack-optimized industrial server designed for deterministic control and data-heavy applications. This unit features dual server-grade processors and high-capacity system memory, making it an ideal hardware platform for multi-axis motion control, complex machine vision systems, and SCADA database hosting. Built with an IP20 protection rating and specialized thermal engineering, the server maintains continuous, stable operation under industrial environmental conditions without sacrificing raw computing output.

Features

Dual-Processor Architecture: Equipped with dual Intel Xeon Silver 4109T processors (8 cores per processor, 2.0 GHz) representing TwinCAT 3 performance class 82.
High-Speed Memory: Standard 64 GB DDR4 RAM with Error-Correcting Code (ECC) to prevent data corruption and system crashes.
Expandable PCIe Slots: Features three PCIe-x8 and three PCIe-x16 slots supporting full-length expansion cards, such as dedicated EtherCAT interface cards or vision grabbers.
10-Gigabit Network Integration: Built-in dual 10GBASE-T Ethernet interfaces provide ultra-high-bandwidth connectivity for machine networks and enterprise systems.
Redundant Storage Options: On-board SATA RAID 1 controller with two front-accessible, removable drive frames for rapid maintenance and hot-swap capabilities.

Applications

High-End Multi-Axis Motion Control: Real-time coordination of complex robotic kinematic profiles via TwinCAT 3.
Machine Vision and Inspection: Direct processing of multiple high-resolution industrial camera streams.
Local Cloud and Virtualization: Hosting virtualization layers (such as Hyper-V or VMware) to run edge applications alongside real-time control software.
Industrial SCADA & MES: Serving as the localized database repository and control hub for manufacturing execution systems.

Technical Specifications

Parameter	Specification
Manufacturer	Beckhoff
Model / Article Number	C6670-0010
Device Type	6-slot SSI EEB industrial server for control cabinet installation
Processor Configuration	2 x Intel Xeon Silver 4109T (2.0 GHz, 8 cores per CPU)
TwinCAT 3 Performance Class	Platform Level 82
System Memory (RAM)	64 GB DDR4 RAM ECC (expandable up to 1024 GB)
PCIe Expansion Slots	3 x PCIe-x8 slots, 3 x PCIe-x16 slots (for full-length cards)
Storage Interface & Drive Bays	On-board SATA RAID 1, 2 x removable frames (1 x 1 TB 3.5-inch HDD included)
Graphics Interface	PCIe graphics card with 1 x DVI-I and 1 x DVI-D connector
On-board Ethernet Ports	2 x 10GBASE-T network interfaces
Power Supply Input	100 to 240 V AC
Ingress Protection Rating	IP20
Operating Temperature	0 to 50 degC
Device Dimensions (W x H x D)	410 mm x 480 mm x 201 mm (16.1 in x 18.9 in x 7.9 in)
Shipping Weight	17.0 kg (37.4 lbs)

Connections and Interfaces

Interface Port	Function / Assignment
2 x RJ45 10GBASE-T	On-board high-speed uplink and machine network connectivity
2 x USB 3.0	External high-speed peripheral and backup drive connections
2 x USB 2.0	Standard input peripheral interfaces (Keyboard/Mouse)
1 x RS232 (D-Sub 9)	Serial communication for legacy devices or terminal management
1 x DVI-I / 1 x DVI-D	Dual display outputs driven by dedicated PCIe graphics card

Empirical Engineering Insights

Alternative Models & Compatibility

The C6670-0010 model utilizes the dual Intel Xeon Silver 4109T configuration, falling into TwinCAT 3 performance class 82. Users looking to upgrade or cross-reference should note that higher tier variants with Intel Xeon Gold 6138T processors increase the licensing performance requirement to TC3 class 84. When replacing or redeploying, verify your TwinCAT runtime licenses match the exact processor platform class to avoid core allocation activation errors.

Application Pitfalls & Engineering Notes

Operating dual Xeon processors in an enclosed IP20 cabinet generates substantial thermal load. Adequate ventilation and airflow management are critical; dynamic CPU throttling will occur if the internal hardware temperature sensor surpasses safety limits, directly impacting the determinism of real-time control routines. It is highly recommended to install cabinet extraction fans to maintain a stable ambient environment below 50 degC.

Commissioning & Wiring Tips

When routing the 10-Gigabit Ethernet connections for industrial communications or vision processing, utilize high-quality Cat6A or Cat7 shielded twisted pair (S/FTP) cabling. Ensure the server's rack ear mounts make solid, low-impedance contact with the cabinet's grounded backplate to divert high-frequency electromagnetic noise away from internal system components.

Installation Guidelines

CRITICAL WARNING: De-energize all incoming power supplies before executing installation, mounting, or cable connection steps. Ensure residual electrical charge in power conditioners or adjacent modules is completely discharged. Failure to follow industrial safety protocols may cause severe equipment damage or electrical shock.

Position the server chassis within the control cabinet, ensuring a minimum vertical clearance of 100 mm above and below the cooling vents to facilitate convection.

Secure the unit using standard M6 mounting screws through the front rack-mount brackets directly into the cabinet framework.

Connect a heavy-duty copper grounding strap from the designated chassis grounding stud to the central protective earth (PE) busbar of the enclosure.

Insert and secure the AC power connection, then connect network (Ethernet) and serial interfaces using shielded, industrial-grade patch leads.

Key Features:

What is the TwinCAT 3 performance class of the C6670-0010?

The C6670-0010 is equipped with dual Intel Xeon Silver 4109T processors, placing it in TwinCAT 3 Platform Level 82. This rating is required for licensing correct software runtime tasks.

What are the memory specifications and limits for this industrial server?

This server comes standard with 64 GB of DDR4 ECC RAM, which protects the system against single-bit memory errors. The server motherboard supports configuration expansions up to 1024 GB.

Are storage drives on the C6670-0010 hot-swappable?

Yes, the unit features two front-accessible drive bays managed by an on-board SATA RAID 1 controller. Drives can be quickly serviced or replaced via these removable frames.

What network interfaces are available directly on the board?

The C6670-0010 features two integrated 10GBASE-T Ethernet RJ45 network interfaces, enabling ultra-fast data transfer with factory networks, virtualization backbones, or vision systems.
