Omron CS1G-CPU44H CS1 Series CPU Unit

Description

Processing speeds and system flexibility are significantly enhanced when integrating the CS1G-CPU44H central processing unit into industrial automation configurations. This high-performance CPU module belongs to the Omron CS1 Series of programmable logic controllers, engineered to coordinate complex process control tasks and machine automation with fast instruction execution times.

Designed for medium-scale system environments, this controller manages a substantial memory and instruction block allocation. It facilitates seamless communication routing across multi-tier networks, optimizing synchronization between localized I/O nodes, HMI interfaces, and supervisory control systems. Its physical construction is robustly engineered to withstand demanding industrial environments while mounting securely to standard backplanes.

Features

• Highly reliable program capacity of 30K steps to handle complex sequencing and computational logic.
• Substantial 64K words data memory storage allocation, suitable for recipe storage and detailed parameter tracking.
• Integrated support for up to 1,280 local and remote input/output points.
• Rack-mounted design for direct mechanical and electrical connection to the system backplane.
• Fast execution speed of basic instructions to minimize cycle time overhead in critical applications.

Applications

• Automated assembly and conveyor line synchronization.
• Water and wastewater municipal treatment control structures.
• Packaging, sorting, and material handling systems.
• HVAC and environmental control systems in commercial or industrial settings.

Technical Specifications

Installation Guidelines

Before installing or removing the CS1G-CPU44H, isolate and switch off all external power supplies connected to the rack assembly. Carefully align the module connectors with the backplane slot guides and insert the unit firmly. Secure the mounting lock mechanism to ensure the CPU is locked in place and shielded against vibration. Maintain adequate clearance around the rack assembly to ensure continuous convective ventilation and prevent hot-spot formation inside the electrical cabinet.

Compliance and Certifications

• CE Certified
