Schneider Electric BMXDAI1604H Modicon X80 Digital Input Module

Description

The BMXDAI1604H is a high-performance discrete input module designed for the Modicon X80 platform, commonly used with the Modicon M340 PLC system. This module features 16 discrete inputs capable of processing 100-120 V AC signals, providing reliable signal acquisition for industrial automation tasks. Built with the precision expected of the Schneider Electric Modicon range, the module offers high reliability and seamless integration into existing rack configurations, making it a robust choice for critical input monitoring and control applications.

Features

• Discrete Inputs: 16 independent input channels
• Voltage Rating: 100-120 V AC
• Compatibility: Designed for the Modicon X80 / M340 platform
• Design: Compact form factor for efficient rack density
• Reliability: High-precision input management for industrial environments

Applications

• Industrial machine control and monitoring
• AC signal detection in automation panels
• Critical production process feedback
• System integration with Modicon M340 / X80 architecture

Technical Specifications

Installation Guidelines

• Mounting: Secure the module into the designated slot on the Modicon X80/M340 rack. Ensure it is fully seated to guarantee a reliable backplane connection.
• Wiring: Connect the 100-120 V AC input signals according to the wiring diagram in the user manual. Use correct wire cross-sections for secure terminal contact.
• Safety: Ensure the input signals are powered down during installation. Verify voltage levels match the module's 100-120 V AC specification before energizing to prevent component damage.
• Environment: Operate in an environment free of conductive dust and excessive moisture to maintain the integrity of the digital circuits.
