The 1756-L950TPSXT (1756L950TPSXT) is a flagship, high-performance ControlLogix 5590 controller specifically engineered for the Process XT (Extended Temperature) environment. This "Extreme" version of the L9 series is designed to thrive in harsh conditions where standard controllers fail, offering a temperature range from -25 to +70 °C. Featuring a massive 50 MB of user memory, the 1756-L950TPSXT is the definitive choice for large-scale process automation, such as offshore oil platforms, remote pipeline monitoring, and heavy chemical refineries. It integrates advanced security features and high-speed embedded Ethernet (1 Gbps) to manage the most data-intensive process control tasks with mission-critical reliability.
The 1756-L950TPSXT is built on the latest Logix engine, providing significant performance leaps over previous generations in both execution speed and communication throughput.
Conformal Coating: Includes factory-applied conformal coating as standard to protect internal circuitry against moisture, dust, and corrosive chemical atmospheres (Class G3 environment protection).
Gigabit Ethernet Port: Features a front-facing 1 Gbps EtherNet/IP port, supporting high-speed device integration, DLR (Device Level Ring) topologies, and high-capacity data producer/consumer models.
Massive 50 MB Memory: Provides the largest memory capacity in its class, allowing for extensive historical data buffering, complex process sequencing, and the storage of large Asset Management (DTM) profiles.
Energy Storage Module (ESM): Eliminates the need for lithium batteries. The controller uses an internal capacitor-based ESM to safely write volatile RAM to non-volatile flash memory during a power loss event.
| Specification | Details |
| Model | 1756-L950TPSXT |
| Manufacturer | Allen-Bradley / Rockwell Automation |
| User Memory | 50 MB |
| Temperature Rating | -25 to +70 Celsius (Extreme Temperature) |
| Communication | 1 Gbps Embedded Ethernet |
| Max EtherNet/IP Nodes | Up to 300 |
| Memory Protection | Energy Storage Module (No Battery Required) |
| Security | Digital Signatures, Encrypted Firmware, Role-Based Access |
| Conformal Coating | Yes (Standard) |
| Shipping Weight | 1.2 kg |
What is the specific benefit of the "Process" (P) designation in this model?
The "Process" designation signifies that the controller is optimized for the PlantPAx distributed control system. It includes instructions and internal logic specifically tuned for process industries, such as advanced PID control, alarm management, and simplified integration with process fieldbus devices.
How does the "XT" version differ from the standard L95?
The XT (Extended Temperature) version uses specialized components and a robust mechanical design to expand the operating window. While a standard L95 is rated for 0–60 °C, the L950TPSXT handles -25–70 °C, making it suitable for unconditioned cabinets in extreme climates.
Can I use the USB port for continuous communication?
No. The integrated USB 2.0 port is intended for temporary use, such as local programming, configuration, and firmware updates. For continuous high-speed data exchange with HMIs or other PLCs, the 1 Gbps Ethernet port should always be used.
Thermal Management: Even though the module is rated for 70 °C, it is critical to ensure proper spacing in the 1756 chassis. Maintain at least 50 mm (2 in.) of clearance around the chassis to allow for natural convection, especially if using a high-density XT power supply.
Firmware Lifecycle: Given the security-hardened nature of the L9 series, ensure the controller is flashed with the latest "Signed" firmware revision. This prevents the execution of unauthorized code and protects the system from firmware-level cyber threats.
Corrosive Environment Care: While conformally coated, the external pins of the backplane and the Ethernet jack are still metallic. In highly corrosive environments, the use of a sealed, pressurized enclosure (NEMA 4X) is recommended to prevent connector oxidation over long periods.
The 1756-L950TPSXT represents the pinnacle of process reliability. By combining "Extreme" hardware durability with "Process" optimized software instructions, it reduces the complexity of designing large-scale control systems for hazardous or remote locations. Its 1 Gbps communication capability ensures that even as the "Industrial Internet of Things" (IIoT) adds more sensors and data points to the network, the controller will not become a bottleneck. This is the ideal controller for users migrating from legacy DCS systems to a modern, high-performance Logix environment that must operate in the most unforgiving conditions on Earth.
