ABB 3ASD573001A5 YPQ 110A Legacy DC Drives Mixed I/O Board

SKU 3ASD573001A5

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: 3ASD573001A5
Origin Sweden
Product Type: Mixed I/O Board
Barcode: 85389091
Payment: T/T, Western Union
Weight: 0.58 kg
Dimensions: 28.0 cm x 21.0 cm x 6.5 cm
Shipping port: Xiamen
Warranty: 12 months

Product Description

The ABB 3ASD573001A5 YPQ 110A is an industrial mixed input and output interface module engineered for legacy direct current and medium voltage alternating current drive control networks. Operating within critical processing systems, this ABB YPQ 110A board bridges field-level digital and analog telemetry with the drive processor to manage real-time loop feedback and internal control sequences. The hardware assembly is optimized for stable operations inside high-power power electronics enclosures, mitigating electromagnetic coupling and ensuring deterministic signal conditioning for heavy industrial drive infrastructures.

Features

Consolidated Subsystem Design: Integrates mixed input and output channels onto a single printed circuit board assembly to reduce internal drive wiring complexity and point-to-point interconnect paths.
Factory-Calibrated Interfaces: Features dedicated signal processing circuitry engineered to interface seamlessly with the processing backplane of legacy ABB drive units.
Direct Form-Factor Compatibility: Serves as a direct-fit component for specialized drive control slots, maintaining strict signal integrity and mechanical alignment parameters.
Interchangeable Support Pathway: Maintains structural compatibility with standard upgrade profiles, enabling straightforward migrations to updated platform architectures when system modernizations are mandated.

Applications

Legacy DC Drive Systems: Installed as a core interface layer within classic ABB YGMV, YGMW, YHMV, and YHMW direct current drive topologies.
Medium Voltage AC Infrastructure: Deployed inside TYRAK LCI legacy medium voltage alternating current drives to execute complex, high-power automation tasks.
Heavy Industry Power Control: Utilized across metals, mining, and paper processing facilities where precise torque, speed, and feedback loops are regulated via centralized legacy drive control units.

Technical Specifications

Parameter	Specification
Manufacturer	ABB Drives
Type Designation	YPQ 110A
Product ID	3ASD573001A5
Module Classification	Mixed Input / Output Board
Customs Tariff Number	85389091
Replacement OEM Product ID	DCF1061142R0001
Product Net Weight	0.58 kg
Country of Origin	Sweden
Shipping Weight (Calculated)	1.15 kg
Package Dimensions (Calculated)	28.0 cm x 21.0 cm x 6.5 cm

Installation Guidelines

CRITICAL WARNING: HIGH VOLTAGE RISK

Completely de-energize the host DC or AC drive system before attempting card extraction or insertion. Verify that all auxiliary supply lines, field wiring signals, and bus bars are fully isolated. Lock-out and tag-out (LOTO) procedures must be enforced to prevent accidental capacitor discharge or incoming line reconnection during maintenance operations.

1 Don a properly grounded electrostatic discharge wrist strap and attach it to a verified metallic earth reference on the drive framework before removing the card from its static-shielded packaging.
2 Inspect the drive subrack slot rails for debris. Carefully realign the module card-edge connectors with the targeted backplane socket keys.
3 Press firmly and evenly on the front faceplate handles until the module is fully seated into the bus. Tighten the retaining hardware to the specified torque limits to establish a proper electrical chassis ground.
4 Reconnect all terminal blocks and signal harnesses. Perform a physical inspection to confirm that no wire strands are shorted to adjacent pathways before initiating the power-up sequence.

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

Which specific drive series utilize this mixed input/output board?

This module is deployed within legacy direct current systems including YGMV, YGMW, YHMV, and YHMW series, as well as TYRAK LCI medium voltage AC drives.

What is the recommended replacement part number if this module is discontinued?

The manufacturer designates the module with ID DCF1061142R0001 as the direct functional replacement product.

Does the installation of this assembly require active static precautions?

Yes. This printed circuit assembly contains sensitive solid-state electronics. A grounded electrostatic discharge wrist strap must be worn during handling.

Is field-side terminal calibration required during initial commissioning?

The board utilizes factory-standard calibrations aligned to native drive system architectures, but full signal verification across connected field instruments must be checked prior to operations.
