ABB 3BHE014135R0011 UA D149 A00-0-11 AC 800PEC Combi IO

SKU 3BHE014135R0011 UAD149A00-0-11

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: 3BHE014135R0011 UAD149A00-0-11
Origin Switzerland
Product Type: I/O Modules
Barcode: 8537101190
Payment: T/T, Western Union
Weight: 0.011 kg
Dimensions: 150 mm x 120 mm x 30 mm (H x W x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The ABB 3BHE014135R0011 UA D149 A00-0-11 is a universal remote Combination Input/Output (Combi IO) module designed for high-speed applications within the AC 800PEC control system. The unit is primarily used for sensing actual values in fast closed-loop control and protection circuits. The module comprises the basic module UA D141, which can be equipped with stackable Combination Input/Output (Combi IO) boards, low voltage divider boards (up to 1000 V), and CT/VT sub-boards to adapt to various voltage and current levels.

Features

Universal remote Combination Input/Output (Combi IO) device designed specifically for fast signal exchange and protection circuits.
Comprises the basic module UA D141 and supports stackable Combination Input/Output (Combi IO) boards.
Supports up to 2 Mixed Combination Input/Output (Combi IO) boards (UA D142), each offering 16 fast digital inputs, 8 fast digital outputs, 6 fast analog inputs, and 2 fast analog outputs.
Supports 1 Traction Module (DA D143) alternative, featuring 13 analog inputs with predetermined characteristics and 18 digital inputs for monitoring tasks.
Combines with low voltage divider boards (up to 1000 V) and CT/VT sub-boards for custom voltage and current scaling.
Optical fiber-optic links to the processor for noise-immune internal communication.

Applications

High-speed closed-loop process control and power electronics protection
Large-scale power converters and industrial drive systems
Power generation, energy distribution, and traction applications
Process industry automation requiring fast signal processing

Technical Specifications

Parameter	Specification
Manufacturer	ABB
Product ID	3BHE014135R0011
ABB Type Designation	UA D149 A00-0-11
Product Name	AC 800PEC Combi IO (Combination Input/Output)
Basic Module Base	UA D141
UA D142 Mixed I/O Board Capacity (Max 2)	16 Fast DI, 8 Fast DO, 6 Fast AI, 2 Fast AO (per board)
DA D143 Traction Module Capacity (Alt 1)	13 AI (predetermined characteristics), 18 DI (monitoring)
Voltage Scaling Interface	Low Voltage Divider boards (up to 1000 V), CT/VT sub-boards
Part Type	New
Gross Weight	0.011 kg
Product Net Weight	0.011 kg
Country of Origin	China (CN) / Switzerland (CH)
Customs Tariff Number	85049099
Minimum Order Quantity	1 piece

Installation Guidelines

Rail Installation: Mount modules onto standard DIN rails in distributed process enclosures.
Optical Wiring: Connect internal I/O communications to the controller using optical links to prevent electrical interference.
Handling Protection: Ensure strict anti-static precautions are taken during handling and mounting of electronic circuit sub-boards.
Thermal Management: Position modules to allow unhindered natural convection, following energy-efficient layout practices.
