3BSE081638R1 PM867K02

ABB

ABB 3BSE081638R1 PM867K02 AC 800M Redundant Processor Unit HI

SKU 3BSE081638R1 PM867K02

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: 3BSE081638R1 PM867K02
  • Origin United States
  • Product Type: Redundant Processor Unit
  • Barcode: 85371091
  • Payment: T/T, Western Union
  • Weight: 2.7 kg
  • Dimensions: 119 mm x 186 mm x 135 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

AC 800M Redundant Processor Units

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB 3BSE081638R1 PM867K02 AC 800M Redundant Processor Unit HI

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB 3BSE081638R1 PM867K02 is a High Integrity Redundant Processor Unit HI engineered for the AC 800M control system platform. Certified for SIL3 safety applications, this central processing unit executes safety-critical logic and process automation tasks. Operating at 133 MHz with 64 MB of memory, the PM867K02 package requires system configuration in strict accordance with the official Safety Manual. The unit is compatible exclusively with System 800xA version 6.0.2 and later releases.

Features

  • Certified for SIL3 high-integrity safety applications
  • Dual PM867 CPU hardware operating at 133 MHz with 64 MB memory
  • Package includes TP830 baseplates, TB807 ModuleBus terminators, TK850 CEX-bus extension cable, and TK851 RCU-Link cable
  • Complete hardware set equipped with two lithium backup batteries for memory retention
  • Compatible with ABB System 800xA version 6.0.2 and higher

Applications

  • High-integrity safety instrumented systems (SIS)
  • Emergency shutdown (ESD) systems requiring SIL3 compliance
  • Industrial process safety and control within ABB System 800xA environments

Technical Specifications

Parameter Specification
Manufacturer ABB
Product ID 3BSE081638R1
ABB Type Designation PM867K02
Product Type Central Unit / Redundant Processor Unit HI
System Compatibility System 800xA 6.0.2 and onwards
Safety Certification SIL3
Processor Clock Speed 133 MHz
Memory 64 MB
Included CPU Modules 2 pcs PM867 CPU
Included Baseplates 2 pcs TP830
Included Bus Terminators 2 pcs TB807 ModuleBus terminator
Included Cables TK850 CEX-bus extension cable, TK851 RCU-Link cable
Backup Battery 2 pcs Lithium batteries (part number 4943013-6), 9 g each
Software License No license included
Dimensions (W x H x D) 119 mm x 186 mm x 135 mm
Product Net Weight 2.7 kg
Customs Tariff Number 85371091



Installation Guidelines

  • Configure the processor unit strictly according to the ABB Safety Manual to ensure compliance with SIL3 requirements.
  • Ensure local organization compliance with ABB safety system qualification requirements prior to ordering and deployment.
  • Mount the CPU modules using the supplied TP830 baseplates.
  • Connect the redundant units using the TK851 RCU-Link cable and establish bus extension using the TK850 CEX-bus cable.
  • Fit the TB807 ModuleBus terminators to secure communication line termination.
  • Install the memory backup batteries (part number 4943013-6) into the designated slots following lithium battery handling procedures.

Compliance and Certifications

  • Safety Integrity Level: Certified for SIL3
  • RoHS Compliance: Following EU Directive 2011/65/EU
  • WEEE Category: Category 5 (Small Equipment - No External Dimension More Than 50 cm)
  • Dangerous Goods Transport: UN3091-PI970 (Lithium Metal Batteries)
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What system versions are compatible with this processor unit?
The device is compatible exclusively with System 800xA version 6.0.2 and later releases.
What safety rating does this central unit hold?
The unit is certified for SIL3 high-integrity safety applications when configured according to the Safety Manual.
What components are included in the package?
The package includes two PM867 CPUs, two TP830 baseplates, two TB807 ModuleBus terminators, a TK850 CEX-bus extension cable, a TK851 RCU-Link cable, and two memory backup batteries.
Does the package include a software license?
No, software licenses are not included with this unit package.
