ABB ACS2000 PBA E10 A01: 6k100 3BHB024711R0020 Phase Module

SKU 3BHB024711R0020

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: 3BHB024711R0020
  • Origin United States, Poland
  • Product Type: Phase Module
  • Barcode: 85044087
  • Payment: T/T, Western Union
  • Weight: 37.0 kg
  • Dimensions: 650 x 400 x 650 mm (W x H x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

ACS2000 Phase Module

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB ACS2000 PBA E10 A01: 6k100 3BHB024711R0020 Phase Module

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB PBA E10 A01: 6k100 3BHB024711R0020 (PBAE10A01 3BHB024711R0020) is a power phase module designed for industrial drive applications. The unit incorporates a 3x47uF internal capacitor configuration and provides essential switching and power conversion capability within compatible drive assemblies.

Features

  • Mechanically identical design across direct replacement variants
  • Integrates 3x47uF capacitance configuration within the phase module architecture

Applications

  • ABB industrial variable speed drive power units
  • Active Front End (AFE) drive systems
  • Drives equipped with sine output filters

Ordering Information

Product ID Type Designation Description
3BHB024711R0020 PBA E10 A01: 6k100 PHASE MODULE 3X47UF

Technical Specifications

Parameter Value
Manufacturer ABB
Product ID 3BHB024711R0020
ABB Type Designation PBA E10 A01: 6k100
Product Name PHASE MODULE 3X47UF
Product Net Weight 37 kg
Country of Origin United States, Poland
Customs Tariff Number 85044087

Installation Guidelines

  • Ensure proper mechanical mounting inside the drive chassis as all replaced modules share identical mechanical dimensions.
  • If replacing part number 3BHB024711R0010 in a system that includes a sine output filter or an Active Front End (AFE) drive, interface cable 3BHB036579R0001 must be ordered and connected.
  • Verify software and firmware requirements prior to commissioning, as on-site programming by a certified Field Service Engineer (FSE) may be required.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What additional hardware is required when replacing older 3BHB024711R0010 modules?
If the drive features a sine output filter or uses an Active Front End (AFE) configuration, interface cable 3BHB036579R0001 must also be ordered.
Is software or firmware configuration required during installation?
The module contains firmware or software that may require on-site programming by a certified Field Service Engineer.
Are older module variants physically compatible with this unit?
Yes, all replaced module variants listed for this product are mechanically identical.
