ABB PFTL 101A-1.0kN 3BSE004166R1 Pressductor Load Cell

SKU 3BSE004166R1

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: 3BSE004166R1
  • Origin Switzerland
  • Product Type: Load Cells
  • Payment: T/T, Western Union
  • Weight: 9.0 kg
  • Dimensions: 160 mm x 120 mm x 200 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Load Cells

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB PFTL 101A-1.0kN 3BSE004166R1 Pressductor Load Cell

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB PFTL 101A-1.0kN (Product ID: 3BSE004166R1) is a horizontal load cell designed for web tension measurement in processing industries. Utilizing Pressductor magnetoelastic technology, it measures horizontal roll force components to enable web tension monitoring in continuous processing applications.

Features

  • Pressductor magnetoelastic measurement technology
  • Designed for horizontal force measurement in web tension applications
  • Rated for force measurement up to 1.0 kN

Applications

  • Web tension measurement in paper, film, and converting machines
  • Processing line roll force sensing
  • Industrial web tension control systems

Technical Specifications

Parameter Specification
Manufacturer ABB
Model PFTL 101A-1.0kN
Product ID 3BSE004166R1
Nominal Force Rating 1.0 kN
Country of Origin Sweden / United States
Product Net Weight 9 kg

Installation Guidelines

  • Mount securely on a rigid structural base to prevent mechanical deflection under load.
  • Ensure proper mechanical alignment with respect to the web force vector.
  • Route measurement cabling away from high-voltage cables and sources of electromagnetic interference.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary application of the load cell?
The load cell is designed for horizontal force and web tension measurement in industrial processing systems.
What is the nominal load capacity of the device?
The nominal force rating for the unit is 1.0 kN.
What is the product weight specified in the technical data?
The net weight of the device is 9 kg.
