ABB AI810 3BSE008516R1 S800 I/O Analog Input Module

SKU AI810 3BSE008516R1

Disponibile

12-month warranty
Free returns within 30 days

Manufacturer: ABB
Product No.: AI810 3BSE008516R1
Origin Sweden
Product Type: Analog Input Module
Barcode: 85389091
Payment: T/T, Western Union
Weight: 0.2 kg
Dimensions: 45 mm x 119 mm x 102 mm (W x H x D)
Shipping port: Xiamen
Warranty: 12 months

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Quantità

Call sales Contact

Product Description

Description

The ABB 3BSE008516R1 is an analog input module designed for acquisition of process measurement signals in industrial control automation environments. The AI810 provides 8 single-ended input channels with 12-bit resolution, supporting standard voltage and current loops including 0..10V and 0(4)..20mA. It integrates within the S800 I/O system, connecting via compatible module termination units.

Features

Provides 8 single-ended analog input channels.
Supports input range signals of 0(4)..20mA and 0..10V.
Features 12-bit conversion resolution.
Designed for mounting on dedicated Module Termination Units (TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, TU850).

Applications

System integration with ABB System 800xA, Compact Product Suite, Advant OCS with Master SW, and Advant OCS with MOD 300 SW.
Industrial process monitoring involving 0(4)..20mA transmitter loops and 0..10V field instrumentation.
Measurement integration in process control systems.

Ordering Information

Product ID	ABB Type Designation	Catalog Description
3BSE008516R1	AI810	AI810 Analog Input 8 ch

Technical Specifications

Parameter	Details
Manufacturer	ABB
Product ID	3BSE008516R1
ABB Type Designation	AI810
Product Type	Analog Input Module
Channel Type	AI
Number of Input Channels	8
Number of Output Channels	0
Input Signal Range	0(4)..20mA, 0..10V
Resolution	12 Bit
Topology	Single ended
HS Code	853890
Customs Tariff Number	85389099
Product Net Width	45 mm
Product Net Height	119 mm
Product Net Depth / Length	102 mm
Product Net Weight	0.2 kg

Installation Guidelines

Mount the module into a compatible Module Termination Unit (such as TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, or TU850).
Ensure proper terminal connection alignment prior to locking the module in place.

Compliance and Certifications

EU Directive 2011/65/EU (RoHS)
WEEE Category: 5. Small Equipment (No External Dimension More Than 50 cm)

Shipping & Returns

Global Express Shipping

Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
12-Month Warranty: Every industrial component is backed by our technical warranty.

FAQ

How many channels are available on the module?

The module features 8 single-ended analog input channels for process signals.

Which input signal types does the unit support?

The unit supports 0(4)..20mA current and 0..10V voltage input signal ranges.

Which termination units are compatible with the module?

The module operates with termination units including TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, and TU850.
