ABB HESG447220R4 70EB02C-ES Procontrol P13/P14 Input Module

SKU HESG447220R4 70EB02C-ES

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: HESG447220R4 70EB02C-ES
  • Origin Sweden
  • Product Type: Power Supply Units
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 0.2 kg
  • Dimensions: 1.6 x 20 x 14.7 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Input Modules Procontrol P13 Procontrol P14
Quantità
Call sales Contact

Product Description

Description

The ABB HESG447220R4 70EB02C-ES is a specialized input module designed for contact signal acquisition within ABB Procontrol P13 and P14 automation systems. As an essential interface device, the HESG447220R4 70EB02C-ES converts signals from field single-throw or double-throw contacts into a 16-bit binary word for system logic processing. The module provides 48Vdc wetting voltage for dry-contact devices, enabling fast data update rates of 50us across 16 logic channels.

Features

  • 16 contact input channels for 48Vdc logic signals
  • Integrated 48Vdc wetting power for dry contact devices
  • Fast 50us data update rate for real-time signal monitoring
  • 16-bit binary word output data format
  • Mobile device and desktop diagnosis capabilities
  • Compatible with both single-throw and double-throw contact configurations

Applications

  • Power generation control systems
  • Industrial automation processes using ABB Procontrol P13/P14 platforms
  • Field contact state monitoring and signal processing

Technical Specifications

Parameter Specification
Manufacturer ABB
Product Model 70EB02C-ES
Spare Model HESG447220R4
Tariff Code 8537101190
Country of Origin SWEDEN
Place of Shipment Xiamen, China
Dimensions 1.6 x 20 x 14.7 cm
Weight 0.2 kg
Number of Channels 16 (8)
Input Types 48Vdc (24Vdc)
Input Resistance 9k ohm to -24V
Connection Types Single throw or double throw contacts
Logic '0' Level -24Vdc to 0Vdc
Logic '1' Level +2Vdc to +30Vdc
Data Update Rate 50us
Input Response 22Hz
Wetting Voltage 48Vdc for dry contact devices
Output Format 16-bit Binary Word
Min Operating Voltage +19.5Vdc
Max Operating Voltage +30Vdc
Max Input Voltage 50V

Installation Guidelines

  • Ensure the power supply matches the module operating voltage limits (+19.5Vdc to +30Vdc) prior to installation.
  • Verify input contact connections for single-throw or double-throw configurations to ensure proper dry contact wetting.
  • Maintain proper field cabling routing to reduce electromagnetic interference (EMI) on logic input signals.
  • Securely seat the module into the Procontrol rack system to ensure robust backplane connectivity.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of this module?
The module serves as a 16-channel contact input interface that provides 48Vdc wetting voltage to field contacts and processes signals into a 16-bit binary output format for the control system.
What input connection types are supported by the device?
The module supports both single-throw and double-throw contact connections.
What are the logic voltage threshold levels for the inputs?
Logic '0' level ranges from -24Vdc to 0Vdc, while Logic '1' level ranges from +2Vdc to +30Vdc.
Reviews
