ABB HIEE300766R0001 GD B021 BE01 Gate Control Unit

SKU HIEE300766R0001

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: HIEE300766R0001
  • Origin Switzerland
  • Product Type: Gate Control Unit
  • Barcode: 85372000
  • Payment: T/T, Western Union
  • Weight: 4.2 kg
  • Dimensions: 276 mm x 206 mm x 37 mm (D x W x H)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Drives Gate Control Units

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB HIEE300766R0001 GD B021 BE01 Gate Control Unit

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

The ABB HIEE300766R0001 GD B021 BE01 is a gate control unit designed for power electronics assembly and drive control systems. Often designated as GDB021BE01 or GD B021 BE01, this unit functions as a gate drive interface, providing accurate firing signals and switching control for high-power semiconductor devices within industrial drive systems. Manufactured in Switzerland, the HIEE300766R0001 ensures reliable timing and signal isolation necessary for controlling thyristors or power modules in heavy-duty automation systems.

Features

  • Specialized gate drive control interface module for power electronics systems
  • Precise signal generation for switching power semiconductors
  • Compact physical form factor for integration into drive cabinets
  • Swiss manufacturing origin for high operational quality

Applications

  • Power electronics converter assemblies
  • Large AC and DC drive systems
  • Industrial excitation systems and power conversion equipment

Technical Specifications

Parameter Specification
Manufacturer ABB
Product ID HIEE300766R0001
Model Designation GD B021 BE01 / GDB021BE01
Country of Origin Switzerland
Product Net Width 206 mm
Product Net Height 37 mm
Product Net Depth / Length 276 mm
Product Net Weight 0.42 kg

Installation Guidelines

  • Ensure all power sources to the cabinet are fully isolated prior to installation or maintenance.
  • Handle the board using appropriate Electrostatic Discharge (ESD) protective equipment.
  • Mount the unit firmly inside the designated sub-rack or mounting tray.
  • Verify proper connection and polarization of gate control signal leads before powering on the drive system.
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the gate control unit?
The unit functions as a gate drive interface providing precise switching signals for power semiconductors in drive and conversion systems.
What are the physical dimensions of the module?
The module measures 37 mm in height, 206 mm in width, and 276 mm in depth, with a net weight of 0.42 kg.
Where is this module manufactured?
The module is manufactured in Switzerland.
