ABB PD D500 A101 3BHE037649R0101 is a Control Board designed for ABB industrial automation applications. The board operates with a 24 V DC supply and provides analog voltage input and opto-isolated digital signal processing functions.
The PD D500 A101 3BHE037649R0101 supports 0-10 V DC voltage signal measurement with 12-bit resolution. It provides multiple opto-isolated channels for 24 V DC input signals, enabling integration with industrial control systems.
The control board is designed for industrial environments requiring reliable signal acquisition and control interface functions.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product Model | PD D500 A101 3BHE037649R0101 |
| Product Type | Control Board |
| Operating Voltage | 24 V DC |
| Power Consumption | ≤15 W |
| Voltage Range | 0-10 V DC |
| Resolution | 12-bit |
| Channels | ≥8 opto-isolated |
| Input Signal Level | 24 V DC |
| Operating Temperature | -20 C to +70 C |
| Humidity Tolerance | 5-95% RH (non-condensing) |
| Vibration Resistance | ≤1 g (5-150 Hz per IEC 60068-2-6) |
| Country of Origin | Sweden |
| Weight | 0.24 kg |
| Dimensions | 17 x 8.2 x 7 cm |
| Tariff Code | 8537101190 |
| Interface | Function |
|---|---|
| Analog Voltage Input | 0-10 V DC signal input |
| Digital Input Channels | 24 V DC input signal interface with opto-isolation |
