ABB PS700 1JNL100175-851 MACH 3 Distributed I/O Unit

SKU PS700 1JNL100175-851

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: PS700 1JNL100175-851
  • Origin Sweden
  • Product Type: Distributed I/O Unit
  • Barcode: 8537101190
  • Payment: T/T, Western Union
  • Weight: 3.5 kg
  • Dimensions: 14.5 cm x 18 cm x 15 cm
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Distributed I/O Unit
Quantità
Call sales Contact

Product Description

Description

The PS700 1JNL100175-851 is a high-density industrial hardware assembly designed to provide decentralized signal acquisition and processing within automated process environments. Functioning as a MACH 3 Distributed I/O unit, this module bridges field instrumentation with centralized control systems by managing distinct digital and analog signaling paths. Equipped with built-in infrastructure to handle real-time fieldbus networking, the component executes sub-millisecond synchronization loop updates to maintain operational flow control. The rugged electrical and structural design of the PS700 1JNL100175-851 isolates process channels from common-mode electrical noise and distribution spikes, making it suitable for continuous plant operations across infrastructure sectors.

Features

  • Implements multi-channel signal processing loops to coordinate complex field instrumentation points simultaneously
  • Features robust electrical isolation protection between control logic and high-voltage field wiring terminals
  • Offers synchronized bus cycle management to ensure low-jitter transmission across distributed network networks
  • Built with a durable mechanical frame configured to withstand baseline vibration profiles in industrial installations

Applications

  • Distributed industrial automation plant monitoring and real-time process control execution
  • Multi-channel digital and high-resolution analog signal acquisition networks
  • High-speed fieldbus communication bridging via standard industrial ethernet protocols

Technical Specifications

Parameter Value
Manufacturer ABB
Product Model PS700 1JNL100175-851
Product Parameters MACH 3 Distributed I/O unit
Input Voltage 24V DC (19.2-30V)
Power Consumption 12W (typical), 18W (max)
Backplane Current 800mA (max)
Isolation 1500V AC
Digital Channels 32
Analog Channels 8 (16-bit resolution)
Protocols Supported PROFINET IO, Modbus TCP
Data Rate 100Mbps (full duplex)
Cycle Time <=1ms (synchronized)
Jitter <1us
Tariff Code 8537101190
Country of Origin SWEDEN
Weight 3.5 kg
Operating Temperature -25 degC to +60 degC
Storage Temperature -40 degC to +85 degC
Humidity 5-95% RH (non-condensing)
Vibration 5g @ 10-150Hz

Installation Guidelines

  • Voltage Integrity: Supply the unit via a regulated 24V DC infrastructure baseline, ensuring input line fluctuations remain strictly within the designated 19.2V to 30V functional boundaries.
  • Environmental Mitigation: Mount the assembly inside an appropriately rated protective enclosure to protect components from humidity levels exceeding 95% RH or condensing fluid hazards.
  • Thermal Clearance: Maintain standard ventilation gaps around the chassis frame during structural mounting to ensure airflow regulates operating temperatures between -25 degC and +60 degC.
Shipping &amp; Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What communication protocols does this distributed I/O unit support natively?
The device features integrated network interfaces that support both PROFINET IO and Modbus TCP industrial protocols at data rates up to 100Mbps.
What are the precise channel capacities allocated to this module?
The module contains 32 separate digital channels alongside 8 high-resolution analog channels featuring 16-bit resolution tracking.
What is the expected synchronization performance regarding loop timing?
The unit delivers highly deterministic performance with a synchronized cycle time of less than or equal to 1ms and network jitter under 1us.
Reviews

More from this brand

ABB 1SAP131000R0278 PM5630-2ETH AC500 Processor Module
1SAP131000R0278 PM5630-2ETHABB 1SAP131000R0278 PM5630-2ETH AC500 Processor Module
ABB DSQC 351 3HNE 00006-1 DeviceNet/Interbus Gateway Module
DSQC351 3HNE00006-1ABB DSQC 351 3HNE 00006-1 DeviceNet/Interbus Gateway Module
ABB 3BSE008544R2 AI820-eA S800 I/O Analog Input Module
3BSE008544R2 AI820-eAABB 3BSE008544R2 AI820-eA S800 I/O Analog Input Module
ABB 8VZZ000167H1 DO05 16CH Digital Output w/Relay I/O Module
8VZZ000167H1 DO05ABB 8VZZ000167H1 DO05 16CH Digital Output w/Relay I/O Module

PS700 1JNL100175-851
