ABB RED670 Line Differential Protection Relay

SKU RED670

Disponibile
  • 12-month warranty
  • Free returns within 30 days
  • Manufacturer: ABB
  • Product No.: RED670
  • Origin Switzerland
  • Product Type: Line Differential Protection Relays
  • Payment: T/T, Western Union
  • Weight: 10.0 kg
  • Dimensions: 254.3 mm x 210.1 mm x 242 mm (H x W x D)
  • Shipping port: Xiamen
  • Warranty: 12 months

Tags

Protection Relays

Product Documentation

Technical Datasheet (PDF) Complete specifications and technical drawings.

Technical Datasheet

ABB RED670 Line Differential Protection Relay

Download Open in new tab
Quantità
Call sales Contact

Product Description

Description

ABB RED670 is a line differential protection relay designed for the protection, control, and monitoring of overhead lines and cables in distribution and high-voltage transmission networks. The device delivers phase-segregated current differential protection for heavily loaded lines, multi-terminal configurations, and cable feeders connected to generator block transformers. It supports up to six stabilized current inputs per phase to accommodate multi-breaker arrangements across three to five terminal applications.

The ABB RED670 incorporates charging current compensation to maintain high sensitivity on long overhead lines and underground cables. Inter-IED communication for differential schemes operates via the IEEE C37.94 standard with optional dual-channel redundancy. To ensure uninterrupted protection during differential communication channel outages, the relay features fully independent full-scheme distance protection with quadrilateral and mho characteristics. Additional integrated functions include single-, two-, and three-phase auto-reclosing, synchrocheck, breaker failure protection, disturbance recording, and fault location.

Features

  • Phase-segregated line differential protection with charging current compensation for two to five line terminals
  • Full-scheme line distance protection with selectable quadrilateral and mho characteristics across six independent zones
  • Support for IEEE C37.94 optical communication interfaces with redundant channel capabilities
  • Dual-bias differential slope evaluation with unrestrained instantaneous high-differential tripping
  • Integrated transformer in-zone differential protection with 2nd and 5th harmonic restraint
  • Auto-reclosing functionality for single-, two-, and three-phase tripping with integrated synchrocheck logic
  • Thermal overload, directional overcurrent, undervoltage, overvoltage, and breaker failure backup protection
  • Support for IEC 61850-9-2LE process bus interfacing with up to six Merging Units (MU)

Applications

  • Transmission and distribution overhead line protection
  • Underground cable feeder protection
  • Multi-terminal lines and multi-breaker arrangements (one-and-a-half breaker and ring busbar systems)
  • Cable feeders connecting to generator block transformers
  • T-feeder and line reactor protection using high-impedance differential functions

Technical Specifications

Parameter Specification
Manufacturer ABB / Hitachi Energy
Product Series Relion 670 Series
Device Type Line Differential Protection IED
Main Protection Function Line Differential Protection (87L / 87LT)
Backup Protection Function Full-Scheme Distance Protection (21)
Current Inputs Up to 6 stabilized current inputs per phase
Line Terminal Capacity Up to 5 terminals
Process Bus Communication IEC 61850-9-2LE (Up to 6 Merging Units)
Differential Optical Protocol IEEE C37.94
Station Communication Protocols IEC 61850-8-1, LON, SPA, DNP3.0, IEC 60870-5-103
Tripping Logic Modes Single-phase, two-phase, three-phase
Thermal Protection Temperature Units degC

ABB RED670 Mechanical Specifications

Case Size Height (h) Width (w) Depth (d) Maximum Weight
6U, 1/2 × 19" 254.3 mm 210.1 mm 242 mm ≤10kg
6U, 3/4 × 19" 254.3 mm 322.4 mm 242 mm ≤15kg
6U, 1/1 × 19" (Full Rack) 254.3 mm 434.7 mm 242 mm  ≤18kg

Installation Guidelines

  • Grounding: Connect the terminal server earth pin directly to the main station grounding bar using short, low-impedance grounding strips.
  • Shielding: Ensure all binary I/O, CT/VT analog connections, and communication cables utilize shielded wiring grounded according to substation standards.
  • Optical Interfacing: Route IEEE C37.94 optical fiber cables within dedicated conduit or trays to maintain minimum bending radiuses and prevent mechanical stress.
  • CT Circuit Wiring: Verify secondary CT circuits are shorted prior to disconnecting or servicing terminal blocks to prevent lethal overvoltages.
  • Cooling and Ventilation: Maintain clear vertical airflow clearance above and below the panel-mounted enclosure for thermal dissipation.

ABB RED670 Ordering Numbers

Ordering No Description Function ID Category
1MRK005907-AA Distance protection zone, quadrilateral characteristic ZMQPDIS, ZMQAPDIS Impedance (Alt 1)
1MRK005907-BA Directional impedance quadrilateral ZDRDIR Impedance (Alt 1 & 4)
1MRK005907-CA Phase selection, quadrilateral characteristic with fixed angle FDPSPDIS Impedance (Alt 1, 2 & Opt 3)
1MRK005907-DA Distance measuring zone, quadrilateral characteristic for series compensated lines ZMCPDIS, ZMCAPDIS Impedance (Alt 2)
1MRK005907-EA Directional impedance quadrilateral, including series compensation ZDSRDIR Impedance (Alt 2)
1MRK005907-FA Fullscheme distance protection, mho characteristic ZMHPDIS Impedance (Alt 3)
1MRK005907-GA Fullscheme distance protection, quadrilateral for earth faults ZMMPDIS, ZMMAPDIS Impedance (Alt 3)
1MRK005907-HA Directional impedance element for mho characteristic ZDMRDIR Impedance (Alt 3 & Opt 1)
1MRK005907-KA Additional distance protection directional function for earth faults ZDARDIR Impedance (Alt 3 & Opt 1,2,4)
1MRK005907-LA Mho Impedance supervision logic ZSMGAPC Impedance (Alt 3)
1MRK005907-MA Faulty phase identification with load encroachment FMPSPDIS Impedance (Alt 3 & Opt 1,2,4)
1MRK005907-NA Distance protection zone, quadrilateral characteristic, separate settings ZMRPDIS, ZMRAPDIS Impedance (Alt 4)
1MRK005907-PA Phase selection, quadrilateral characteristic with settable angle FRPSPDIS Impedance (Alt 4)
1MRK005907-SB High speed distance protection, quad and mho characteristic ZMFPDIS Impedance (Alt 5)
1MRK005907-RB High speed distance protection for series compensated lines, quad and mho ZMFCPDIS Impedance (Alt 6)
1MRK005907-UA Power swing detection ZMRPSB Impedance (Optional)
1MRK005908-AA Automatic switch onto fault logic, voltage and current based ZCVPSOF Impedance (Optional)
1MRK005907-VA Power swing logic PSLPSCH Impedance (Optional)
1MRK005908-CB PoleSlip/Out-of-step protection PSPPPAM Impedance (Optional)
1MRK005908-GA Out-of-step protection OOSPPAM Impedance (Optional)
1MRK005908-DA Phase preference logic PPLPHIZ Impedance (Optional)
1MRK005920-AA Scheme communication logic for distance or Overcurrent protection ZCPSCH Scheme Communication
1MRK005920-BA Phase segregated Scheme communication logic for distance protection ZC1PPSCH Scheme Communication
1MRK005920-CA Current reversal and weak-end infeed logic for distance protection ZCRWPSCH Scheme Communication
1MRK005920-DA Current reversal and weak-end infeed logic for phase segregated communication ZC1WPSCH Scheme Communication
1MRK005920-EA Local acceleration logic ZCLCPSCH Scheme Communication
1MRK005920-FA Scheme communication logic for residual overcurrent protection ECPSCH Scheme Communication
1MRK005920-GA Current reversal and weakend infeed logic for residual overcurrent protection ECRWPSCH Scheme Communication
1MRK005921-AX Direct transfer trip DTT Scheme Communication
1MRK005922-MX Configurable logic blocks Q/T - Logic Functions
1MRK005922-AY Extension logic package - Logic Functions
1MRK005924-HA Circuit breaker condition monitoring SSCBR Monitoring
1MRK005925-XB Fault locator LMBRFLO Monitoring
1MRK005930-TA Process Bus communication IEC 61850-9-2 - Station Communication
1MRK002924-YB IEC 62439-3 parallel redundancy protocol PRP Station Communication
Shipping & Returns

Global Express Shipping

  • Standard Delivery: 4–6 business days via DHL, FedEx, and UPS.
  • Express Dispatch: Same-day dispatch for in-stock orders placed before 2:00 PM (GMT+8).
  • Worldwide Coverage: Serving over 150 countries.

Returns & Warranty

  • 30-Day Guarantee: Returns accepted for in-stock products in original, factory-sealed packaging.
  • 12-Month Warranty: Every industrial component is backed by our technical warranty.
FAQ
What is the primary function of the line differential protection relay?
The device provides phase-segregated current differential protection and integrated distance backup protection for overhead transmission lines, cables, and multi-terminal feeder networks.
Which communication standard is used for remote differential data exchange?
The remote differential communication between relays is based on the IEEE C37.94 optical standard.
How many line terminals can the relay support in differential schemes?
The device supports up to three terminals in multi-breaker configurations or up to five terminals in single-breaker configurations.
Does the relay support process bus communication?
Yes, the device supports IEC 61850-9-2LE process bus communication with up to six Merging Units.
