The 3BSE013064R1 is an industrial PC-based interface board developed by ABB to function as an engineering communication node within the Advant OCS architecture. Operating under the type designation PU516, this board bridges system configurations by establishing critical link capabilities directly through a standard 5V, 32-bit, 33MHz PCI bus slot. The 3BSE013064R1 is configured with an integrated hardware interface consisting of one MB300 communication port and one RS-232 serial port, enabling simultaneous high-speed peer-to-peer subsystem linking and localized serial maintenance diagnostics. Equipped with 16 megabytes of onboard memory, the PU516 processor card offloads deterministic data traffic from the host platform, ensuring the stable synchronization required for engineering stations, control networks, and Master software configurations.
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Product ID | 3BSE013064R1 |
| ABB Type Designation | PU516 |
| Product Name | PU516 Engineering Board -PCI |
| Bus Type | PCI bus (5V, 32-bit, 33MHz) |
| Memory Capacity | 16Mbyte |
| Integrated Ports | 1 x MB300 network port, 1 x RS-232 serial port |
| Country of Origin | Sweden (SE) / Germany (DE) |
| Customs Tariff Number | 85389091 |
| Product Net Weight | 0.38 kg |
| Exchange Part Number | EXC3BSE013064R1 |
| Connector / Port | Function |
|---|---|
| MB300 Port | Connects to the MasterBus 300 control network for real-time process data exchange. |
| RS-232 Port | Connects to standard serial diagnostic terminals or localized configuration tools. |
| PCI Edge Connector | Establishes electrical and logical contact with the host 5V 32-bit PCI motherboard slot. |
Turn off all primary power sources supplying the engineering station or host enclosure before opening the assembly. Put on a calibrated anti-static wrist strap connected to a verified ground point. Insert the PU516 board straight down into the designated 5V 32-bit PCI slot until the edge connector makes full contact with the bus terminal, then secure the metal bracket screw.
Use fully shielded cabling for both the MB300 and the RS-232 communication lines. Ground the cable shields explicitly at the designated enclosure entry point to prevent environmental electrical noise from corrupting data registers or disrupting the underlying real-time PCI bus communication timings.
Verify that internal cabinet ventilation routing matches factory specifications. Leave clear airway paths around the 3BSE013064R1 board to prevent localized thermal pockets from affecting the performance of the onboard memory modules and communication transceivers.
Global Express Shipping
Returns & Warranty
Manufacturer: ABB
Product No.: PU516 3BSE013064R1
Country of origin:Sweden
Product Type: Engineering Board
Barcode: 85389091
Payment: T/T, Western Union
Weight: 380g
Dimensions: 32.5 cm x 12.6 cm x 1.7 cm
Shipping port: Xiamen
Warranty: 12 months
